Speed Nut #10-24 Thd. Used w/Single Cylinder Engine Only.
MTD-712-0147
4
Gasket-Exhaust Used w/Single Cylinder Engine Only.
MTD-BS-692236
5
Truss Mach. Scr. 5/16-18 x .75" Used w/Single Cylinder Engine Only.
MTD-710-0323
6
External L-Wash. 5/16" I.D. Used w/Single Cylinder Engine Only.
MTD-736-0607
7
WIRE Used w/Single Cylinder Engine Only.
MTD-725-0980
8
SHIELD-MUF Used w/Single Cylinder Engine Only.
MTD-16936
9
HEAT SHEID ASSEMBLY Used w/Single Cylinder Engine Only.
MTD-683-0042A
10
HEX SCREW AB-TAP #10-16 x 0.500 Used w/Single Cylinder Engine Only.
MTD-910-0224
11
HEX CAP SCREW 1/4-20 x .375 GR5 Used w/Single Cylinder Engine Only. For faster service obtain standard nuts, bolts and washers locally. If items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0294
12
SHOULDER SCREW Used w/Single Cylinder Engine Only.
MTD-938-0636
13
HEX NUT 1/4-20 For faster service obtain standard nuts, bolts and washers locally. If items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-912-0287
Hex Bolt 5/16-18 x .75" Lg. For faster service obtain standard nuts, bolts and washers locally. If items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0118
38
Hex Bolt 1/4-20 x .62" Lg. For faster service obtain standard nuts, bolts and washers locally. If items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0258
HEX NUT 5/16-18 For faster service obtain standard nuts, bolts and washers locally. If items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-712-3010
