Weed Eater FL1500 Gas Blower Type 5, Featherlite

Model: FL1500 Gas Blower Type 5

Back To Assemblies

Save Part Not Listed?
product name

Blower Assembly Type 4 & 5

...
...
1
Handle PLN-530054429
...
2
Nut PLN-530016316
...
3
SCREW PLN-530016386
...
4
Shroud PLN-530057102
...
5
Screw PLN-530016349
...
6
Gasket-Carb.(kit) PLN-530071472
...
7
Air Box PLN-530052333
...
8
Washer PLN-530015123
...
9
Screw PLN-530016349
...
10
Cover-Air Box PLN-530052332
...
11
Foam-Air Filter PLN-530047932
...
12
Screw (Type 4) PLN-530015849
...
12
Screw (Type 5) PLN-530016394
...
13
Carburetor Ass'y. Kit PLN-530071629
...
14
Foam-Air Dam PLN-530057725
...
15
Screw PLN-530016014
...
16
CARBURETOR ADAPTOR PLN-545030402
...
16
Carb. Adaptor (Type 5) PLN-530057634
...
17
Gasket-Carb. Adap.(kit) PLN-530071472
...
18
Inner Bearing PLN-530032125
...
19
Kit-Crankcase Seal PLN-530071615
...
20
Outer Bearing PLN-530055728
...
21
Retainer Ring (C'shaft) PLN-530015941
...
22
CONNECTING ROD ASSY PLN-530049817
...
23
Kit-Piston (Incl. 24,31) PLN-530071833
...
24
RING PISTON PLN-545154001
...
25
Screw PLN-530015953
...
26
Cylinder PLN-530012416
...
27
Spark Plug (RCJ-6Y) PLN-952030249
...
28
Kit-Gasket PLN-530071472
...
29
Muffler Spring PLN-530042088
...
30
Kit-Muffler Ass'y. (incl. #29) PLN-530071574
...
31
Wrist Pin Retainer PLN-530015162
...
32
Gasket-Cylinder(kit) PLN-530071472
...
33
Ignition Module PLN-530039163
...
34
Grommet-Ign. Module PLN-530019182
...
35
Screw PLN-530016357
...
36
SCREW PLN-530016386
...
37
KIT FAN HSG PLN-545081702
...
38
Spring-Starter Dog PLN-530023817
...
39
FLYWHEEL ASSY (Incl. 38) PLN-545221701
...
40
C'case & C'shaft Ass'y. (Incl. 21, 41 & 42) PLN-530071625
...
41
C'case & C'shaft Ass'y. PLN-530071625
...
42
Crankcase Ass'y. (Incl. 18-20) PLN-530071627
...
43
O-Ring C'case (kit) PLN-530071472
...
44
Isolator PLN-530054432
...
45
Kit-Module Spacer & Screws PLN-530071731
...
xx
Operator Manual Not Shown PLN-530164008
...
xx
Decal-Start Inst. Not Shown PLN-530057977
