Weed Eater 1212 Electric Trimmer

Model: 1212 Electric Trimmer

Save
 Part Not Listed?Part Not Listed?
product name

Trimmer Assembly

...
...
1
HANDLE-UPPER PLN-530402060
...
2
Screw PLN-530352036
...
3
Trigger PLN-530347654
...
4
On/Off Switch PLN-530347897
...
6
Wiring Harness PLN-530401672
...
7
Shield 1210-T2 & T3 PLN-530351804
...
7
Shield 1212-T1, T2 & T3 PLN-530351805
...
8
Line Limiter 1210-T1 PLN-530350362
...
8
Line Limiter 1210-T2, T3, & 1212-T1, T2 & T3 PLN-530351802
...
9
Nut PLN-534790500
...
10
Screw PLN-530348050
...
11
Motor Hsg. Set 1210-T2 PLN-530351809
...
11
Motor Hsg. Set 1210-T3 &1212-T1, T2, T3 PLN-530400117
...
12
Motor Assembly 1210-T1 & T2 PLN-530347696
...
12
Motor Assembly 1212-T1 & T2 PLN-530401211
...
12
Motor Assembly 1210-T3 PLN-530400772
...
12
Motor Assembly 1212-T3 PLN-530400772
...
13
Washer PLN-530001717
...
14
Hub PLN-530400008
...
15
Line Saver PLN-530340594
...
16
Spring Cap PLN-530340732
...
17
Drive Gear Ass'y. PLN-530350366
...
18
Cover PLN-530340591
...
19
Spring PLN-530340006
...
20
Spool w/Line PLN-952701521
...
21
Release Button PLN-530340592
...
23
Blade Cover 1210-T2 & T3 PLN-530351801
...
23
Blade Cover 1212-T1, T2 & T3 PLN-530351801
...
24
Screw 1210-T2 & T3 PLN-530351800
...
24
Screw 1212-T1, T2 & T3 PLN-530351800
...
25
Cord Retainer PLN-530347653
...
26
Upper Tube PLN-530348741
...
27
Bolt PLN-530340228
...
28
Assist Handle PLN-530322295
...
29
Wing Nut PLN-530400013
...
30
Screw PLN-530346034
...
31
Lower Tube Assy. PLN-530401367
...
32
Nut PLN-530403094
...
32
Operator's Manual Model 1210 Not Shown PLN-530068743
...
32
Operator's Manual Model 1212 Not Shown PLN-530081429
...
...
...
