Weed Eater 108 Electric Trimmer

Model: 108 Electric Trimmer

Save Part Not Listed?
product name

TRIMMER ASSEMBLY

...
...
1
RECEPTACLE PLN-530092579
...
2
FUSE PLN-530092581
...
3
SWITCH ASSEMBLY PLN-530092582
...
4
SWITCH LOCK PLN-530092583
...
5
HARNESS (Inc. 1, 2, and 3) PLN-530092584
...
6
FOAM SPACER PLN-530092585
...
7
BATTERY PLN-530092586
...
8
BATTERY HSNG. ASSY. w/SWITCH LOCK PLN-530092587
...
9
SCREW PLN-530090827
...
10
ASSIST HANDLE PLN-530092588
...
11
BOLT PLN-530625509
...
12
WING NUT PLN-530092049
...
13
TUBE PLN-530092589
...
14
CONNECTOR PLN-530090876
...
15
MOTOR HOUSING SUB ASSEMBLY PLN-530093764
...
16
MOTOR ASSEMBLY PLN-530093557
...
17
MOTOR MOUNT PLN-530092593
...
18
SCREW PLN-530092594
...
19
HUB PLN-530092595
...
20
TAIL INTERFERENCE BLADE PLN-530090874
...
21
SPOOL ASSEMBLY PLN-702514
...
22
CHARGER PLN-530092597
