product name

Walbro Carburetor WVF-9-1

Model: Carburetor WVF-9-1

Save Part Not Listed?
product name

WVF-9-1 PARTS LIST

...
...
2
O' Ring WLB-16-105
...
3
Ring / Spring R WLB-16-127
...
4
E' Ring WLB-16-300
...
6
Fuel Bowl Assy WLB-20-731-1
...
7
Cover/Piston WLB-21-3352-1
...
8
Cover/Thermos WLB-21-3340-1
...
9
Fuel Fitting Ca WLB-25-172-1
...
11
Throttle Shaft A WLB-30-1460-1
...
12
Throttle Valve WLB-34-413-1
...
14
Hose WLB-71-66
...
15
Air Vent Hose WLB-71-67
...
16
Float Assembly WLB-75-588
...
17
Inlet Valve Ass WLB-82-546
...
20
Main Nozzle WLB-86-3184-270
...
21
Nozzle/Accl WLB-86-3149-36
...
22
Slow Plug WLB-88-222-8
...
24
Brass Ball WLB-89-40
...
25
Screw Assy WLB-96-738
...
26
Screw Assembl WLB-96-3016
...
27
Valve Screw WLB-96-3017-7
...
28
Screw WLB-96-3018-7
...
29
Screw WLB-96-3075
...
30
Spring/Idle Adj WLB-98-3292
...
31
SpringNeedle WLB-98-3295
...
32
Spring/Jet WLB-98-3345
...
33
Spring/Piston WLB-98-3359
...
34
Spring/Thr. Ret WLB-98-3350
...
35
Spring/Accel WLB-98-3349
...
36
Needle/Pilot WLB-102-3438-1
...
37
Needle/Jet WLB-102-3461-1
...
38
Retainer/Jet WLB-108-246
...
39
Jet/Main WLB-112-3037-108-1
...
40
Jet/Slow WLB-112-3040-34
...
41
Jet/Air WLB-112-3041-070
...
42
Jet/Air WLB-112-3041-100
...
43
Jet/Starter WLB-112-3033-110-1
...
44
Jet WLB-112-3077-050
...
45
Tube/Emulsion WLB-122-3333-1
...
46
Fitting WLB-128-3037
...
47
Washer WLB-136-254
...
48
Washer WLB-136-255-8
...
49
Washer WLB-136-274-8
...
50
Pin WLB-144-183
...
55
Piston Assy WLB-160-532-1
...
56
Accelerator Lev WLB-166-514-1
...
57
Bracket WLB-167-166-1
...
58
Starter Cup WLB-169-22-1
