Ultra-Fab 38-944055 Phoenix 5500 Electric Tongue Jack

Model: 38-944055

Save Part Not Listed?
product name

Ultra-Fab 38-944055

...
...
xx
Fuse Holder ULT-38-751035
...
xx
250V 30A Slow-Blow Fuse ULT-38-751034
...
xx
Manual Override Socket- 9/16" ULT-38-751167
...
1
Twist Plug ULT-35-753001
...
2
Plastic Housing Cover ULT-35-753002
...
3
Pcb-Main ULT-38-753019
...
4
Gear Box Cover ULT-38-753012
...
5
Drive Gear ULT-38-753013
...
6
Bevel Gear Assembly ULT-38-753014
...
7
Motor ULT-38-753016
...
8
Led Light ULT-38-753015
...
9
Lens ULT-38-753003
...
10
Motor Housing ULT-38-753004
...
11
Keypad ULT-38-753005
...
13
Collar ULT-38-753021
...
14
Gear Box ULT-38-753017
...
15
Outer Tube ULT-38-753026
...
16
Wire Lock Pin ULT-38-141023
...
17
Footpad Adjustable ULT-38-751101
...
18
Inner Tube ULT-38-753033
...
19
Ball Screw Set ULT-38-753010
...
20
Brake Assembly ULT-38-753024
...
21
Friction Washer ULT-38-753025
Schematic Image Zoomed
