PULLEY Not part of chain case assembly.
MTD-756-0287
8
Hex Bolt 3/8-24 x 2.5" For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0369
9
Belt Cover Brkt. New Part Not part of chain case assembly.
MTD-786-0044
HEX SCREW 1/4-28 x .62 For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-910-0195
L-Wash. 1/4" I.D. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0329
18
Hex Nut 1/4-28 Thd. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-712-0138
Spring Pin Spiral 1/4" Dia. x 11/2" Lg. Not part of chain case assembly.
MTD-715-0114
32
SPACER Not part of chain case assembly.
MTD-750-0550
33
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .38" Lg.
MTD-710-0653
34
Hex Bolt 5/16-18 x .75" For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0118
35
HEX NUT 5/16-18 For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-712-3010
36
Lock Wash. 5/16" I.D. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0119
Hex Bolt 1/4-20 x 2" For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0501
Lock Wash. 5/16" I.D. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0119
Hairpin Cotter For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-714-0145
24
Hex Bolt 5/16-18 x 1" For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0376
Hex Bolt 1/4-20 x 5/8" For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0258
Hex Bolt 5/16-18 x 3/4" For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0118
L-Wash. 1/4" I.D. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0329
Lock Wash. 5/16" I.D. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0119
