L-Wash. 1/4" I.D. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0329
23
HEX NUT 1/4-20 For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-912-0287
HEX NUT 5/16-18 For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-712-3010
Truss Mach. Scr. 5/16-18 x .75" Lg. Used with Single Cylinder Engine Only.
MTD-710-0323
54
WIRE Used with Single Cylinder Engine Only.
MTD-725-0980
56
Spring Wash. .265 I.D. x .562 O.D. Used with Single Cylinder Engine Only.
MTD-936-0175
58
HEX CAP SCREW 1/4-20 x .375 GR5 Used with Single Cylinder Engine Only. For faster service obtain nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0294
60
Hex B-Tap Scr. #10 x .38" Used with Single Cylinder Engine Only.
MTD-910-0429
61
SHOULDER SCREW Used with Single Cylinder Engine Only.
MTD-938-0636
63
Gasket-Exhaust Used with Single Cylinder Engine Only.
MTD-BS-692236
64
HEAT SHEID ASSEMBLY New Part; Used with Single Cylinder Engine Only.
MTD-683-0042A
65
Speed Nut #10-24 Thd. Used with Single Cylinder Engine Only.
MTD-712-0147
