Troy-Bilt TB304S 41BD304S766 Handheld Product

Model: TB304S 41BD304S766

Save
Part Not Listed?Part Not Listed?
product name

Engine Assembly

...
...
1
REAR ENGINE COVER (Incl. 2 & 3) MTD-753-09884

...
2
SCREW 8-16 x 3/4 MTD-710-04194

...
3
SCREW M5-0.8 x 19 MTD-710-04604

...
4
ROCKER COVER MTD-753-05901

...

...
6
O-RING CYL AC5 MTD-753-05910

...
7
BREATHER HOSE MTD-753-10205

...
8
OIL PLUG (Incl. 9) MTD-753-05408

...
9
RING, OIL PLUG (AC MTD-791-182290

...
10
CRANKCASE COVER MTD-753-06259

...
11
O-RING CRNKCSE CVR MTD-753-05238

...
12
FLYWHEEL ASSEMBLY AC3.1 MTD-753-06221

...
13
LEAD WIRES MTD-753-05264

...
14
MODULE ASSEMBLY MTD-753-11255

...
15
MUFFLER ASSEMBLY (Incl. 16 & 17) MTD-753-05245

...
16
GASKET/MUFFLER MTD-753-05244

...
17
SCREW M5 x 44MM MTD-710-04809

...
18
SPARK PLUG 4 CYCL MTD-794-00082

...
19
GASKET/INSULATOR MTD-753-05247

...
20
NUT 10-32 MTD-712-04099

...
21
CARB INSULATOR MTD-841-020801S

...
22

...
23
CARBURETOR MTD-753-11331

...
24
SCREW, M5 X18 MTD-9052-1

...
25
AIR CLEANER COVER (Incl. 26) MTD-841-036210S

...
26
AIR FILTER MTD-753-05254

...
27
SCREW 10-32X2.5 MTD-710-04517

...
28
FUEL TANK ASSEMBLY (Incl. 29) MTD-753-06797

...
29
FUEL CAP ASSEMBLY 43MM-6 W/O HOLE MTD-753-1229

...
30
FUEL TANK PADS MTD-753-05259

...
31
STARTER HOUSING (MTD RED) (Incl.  3 & 38) MTD-753-10204

...
32
CLUTCH ASSEMBLY MTD-753-06281

...
33
CLUTCH COVER (Incl. 2) MTD-753-09887

...
34
SCREW, 8-32 x .312 P MTD-791-182519

...
35

...
36

...
37
SHORT BLOCK (Incl.  3-9, 11, 18, 24<BR/> & 39) MTD-841P021441S

...
38
SPACER :2.165" MTD-750-04434

...
39
SCR, VALVE COVER MTD-791-181025

...
40
HEAT SHIELD MTD-753-06949

...
41
CARBURETOR GASKET MTD-791-181709

...
42
WOODRUFF KEY #403-.125 x .375 MTD-914-04016

General Assembly

...
...
43
THROTTLE GRIP ASM (Incl.  44 - 48) MTD-753-09888

...
44
LEVER LOCK OUT MTD-731-08433C-10

...
45
SW, MOMENTARY ON/O MTD-791-182405

...
46
TRIGGER SPRING MTD-753-05007

...
47
THROTTLE TRIGGER MTD-731-04970B-10

...
48
SHOULDER STRAP CLIP MTD-732-06186

...
49
THROTTLE CABLE MTD-746P04758

...
50
UPPER BOOM MTD-841-035632S

...
51

...
52
HANDLE ASSEMBLY (Incl. 53) MTD-753-06039

...
53
BOLT 1/4-20X1 1/2 MTD-753-06040

...
54
SPLIT BOOM COUPLER KIT (Incl. 55) MTD-753-1190

...
55
SCREW, 10-32X.250 TA MTD-791-182057

...
56
BOOM ASSEMBLY LOWER MTD-753-06789

...
57
LOWER DRIVE SHAFT MTD-753-05267

...
58
GEARBOX LCBC (Incl. 59 - 61) MTD-753-08180

...
59
SCREW, 8-32 x .312 P MTD-791-182519

...
60
SCREW #10-24X11/16 T-25 MTD-791-182195

...
61
CUTTING HEAD SPACER MTD-748-05052

...
62
GUARD/BLADE ASM (Incl. 63 & 64) MTD-841-032093S

...
63
BLADE GUARD MOUNTING HARDWARE MTD-753-04282

...
64
BLADE ASSEMBLY W/HDW MTD-753-08355

...
65
HEAD ASSEMBLY CNT/AF (LH) LRG (Incl. 66) MTD-841-012478S

...
66
BUMP KNOB MTD-753-08563
...
...
...
