Troy-Bilt TB27PS XP 41AD27PX766 Handheld Product

Model: TB27PS XP 41AD27PX766

Save
 Part Not Listed?Part Not Listed?
product name

Engine Assembly

...
...
1
STARTER ASSEMBLY DLX (Incl. 2 & 3) MTD-753-06878
...
2
SCREW:10-32X.5 MTD-1964
...
3
STARTER GUARD (Incl. 2) MTD-753-06244
...
4
REAR ENGINE COVER (Incl. 5) MTD-753-06245
...
5
SCREW, #8-16X.750 PH MTD-791-181345
...
6
Muffler Assembly MTD-753-08745
...
7
SHORT BLOCK ASSEMBLY (Incl. 8 - 15) MTD-753-08582
...
8
SPARK PLUG MTD-753-06847
...
9
SCREW 1/4 x 20 x .8125 MTD-710-04715
...
10
MODULE MTD-753-06892
...
11
GASKET CYL MTD-753-06827
...
12
FLYWHEEL ASSEMBLY 27CC MTD-753-06246
...
13
BELL WASHER MTD-753-06247
...
14
SPACER MTD-753-06248
...
15
WOODRUFF KEY #403-.125 x .375 MTD-914-04016
...
16
INTAKE ASSEMBLY (Incl. 17 & 18) MTD-753-06189
...
17
O-RING MTD-753-06184
...
18
O-RING MTD-753-06185
...
19
CARBURETOR MTD-753-06190
...
20
GASKET CARB MTD-753-06253
...
21
AIR CLEANER COVER (Incl. 22) MTD-753-10084
...
22
AIR FILTER MTD-753-06954
...
23
FUEL TANK ASSEMBLY (Incl. 24 & 25) MTD-753-06250
...
24
FUEL CAP MTD-753-06857
...
25
SCREW:10-6 x .75 MTD-791-181930
...
26
SMALL CLUTCH ASSEMBLY W/SMALL DRUM MTD-753-05860
...
27
THROTTLE CABLE MTD-946-04824
...
28
LEAD WIRES MTD-753-05877
...
29
PAWL ASSEMBLY AC5 MTD-753-06091
...
30
ELECTRIC START ADP MTD-753-06104
...
31
CLUTCH COVER (Incl. 32 - 36) MTD-841-015771S
...
32
SCREW, 8-32 x .312 P MTD-791-182519
...
33
SCREW MTD-9689A
...
34
HEX NUT MTD-712-0161
...
35
NUT, TINNERMAN U-T MTD-791-182366
...
36
SCREW #10-24X11/16 T-25 MTD-791-182195

General Assembly

...
...
37
THROTTLE HOUSING ASSEMBLY (Incl. 38 - 41) MTD-753-08564
...
38
LEVER LOCK OUT MTD-731-08433C-10
...
39
SW, MOMENTARY ON/O MTD-791-182405
...
40
TRIGGER SPRING MTD-753-05007
...
41
THROTTLE TRIGGER MTD-731-11788-10
...
42
HANDLE:D (Incl. 43 & 44) MTD-753-05008
...
43
SCREW MTD-791-181070
...
44
BASE-HANDLE LOOP:COM MTD-753-05009
...
45
BOOM ASSEMBLY UPR MTD-753-06682
...
46
CLAMP-SHOULDER STR MTD-791-610327
...
47
CLICK LINK (Incl. 48) MTD-753-10964
...
48
SCREW, 10-32X.250 TA MTD-791-182057

Pole Saw

...
...
49
24.55" BOOM MTD-753-11299
...
50
30" POLESAW BOOM (Incl. 51) MTD-753-11298
...
51
FLEXIBLE DRIVE SHAFT MTD-753-11123
...
52
SCREW 1/4-20 X.500 MTD-710-0599
...
53
GEAR BOX ASSEMBLY (Incl. 54 & 55) MTD-753-05599
...
54
SPROCKET ASSEMBLY MTD-753-05595
...
55
SCREW 4X40X.50 MTD-710-04696
...
56
SCREW 5/16-18 x 1.25 GR5 MTD-710-0528
...
57
OIL TANK ASSEMBLY MTD-753-05586
...
58
FUEL CAP ASSEMBLY MTD-753-05587
...
59
SCREW, #8-16X.750 PH MTD-791-181345
...
60
OIL LINE MTD-753-05588
...
61
CHAIN TENSION HDW MTD-753-05597
...
62
BAR 10" MTD-795-00442
...
63
CHAIN 10" MTD-713-05156
...
64
CHAIN GUARD MTD-753-05765
...
65
FLANGE LOCK NUT 5/16-18 MTD-712-04063
...
66
SCABBARD MTD-731-25531-2
...
xx
HANGER MTD-731-08926
...
xx
SHOULDER STRAP MTD-795-00233
...
xx
ALLEN WRENCH MTD-797-00056
...
...
...
