Simplicity SYMP.4 Symmetry Upright Vacuum

Model: SYMP.4

Save Part Not Listed?
product name

Simplicity SYMP.4

...
...
xx
HEPA & Charcoal Filter Pkg TAC-SSPF
...
xx
HEPA Bag TAC-SAH-6
...
xx
Hose Air Path Seal(Not Shown) TAC-B388-3600
...
1
Dust Cover Assembly TAC-D224-05B4
...
2
Combination Washer Screw TAC-A732-5300
...
3
HEPA Filter TAC-B222-0900B
...
4
Dust Compartment Side Seal TAC-B221-0213
...
5
Paper Bag 4.6-PLAIN
...
6
Motor Cover B123-0214F
...
7
Motor Cover Seal TAC-B221-0413
...
8
Motor Exhaust Filter TAC-B222-0400
...
9
Secondary Filter TAC-B222-1200B
...
10
Filter Support Screen TAC-B222-0600
...
11
Dust Compartment Seal Lg TAC-B224-2300
...
12
Dust Compartment Seal Sm TAC-B224-0500
...
13
Screw TAC-A732-7300
...
14
Thermal Switch TAC-B333-0400B
...
15
Thermal Switch Lead Wire TAC-B333-0700-C
...
16
Thermal Switch Seal TAC-B333-0600
...
17
Thermal Switch Assembly TAC-D123-1000
...
18
Wire Connector LG TAC-B123-2700
...
19
Motor Cord TAC-B224-0314B
...
20
FBI Assembly TAC-C227-0300B
...
21
Dust Compartment TAC-D224-0414
...
22
Stretch Hose TAC-A225-0114
...
23
Hose Cuff TAC-B625-0314
...
24
Suction Inlet Complete TAC-C625-0114
...
25
Hose Assembly D626-0514
...
26
Power Cord TAC-D434-1700B
...
27
Pressure Switch TAC-B227-1200
...
28
Pressure Switch Mount TAC-B227-0014
...
29
Jumper Switch Wires TAC-B433-0200
...
30
Zip Tie TAC-A732-0100
...
31
Wire Connector MD TAC-B123-0100
...
32
Electrical Connector Female TAC-A235-0400
...
33
Handle Bolt Nut TAC-A432-0605
...
34
Switch Cover Seal TAC-B221-0313
...
35
Switch Cover TAC-B324-0114
...
36
Dust Cover Latch Assembly TAC-C224-0014

Simplicity SYMP.4

...
...
xx
Carpet Floor Switch Detent (Not Shown) TAC-B017-4000
...
1
Nozzle Housing Assembly TAC-D017-07B4
...
2
Headlamp Lens TAC-B018-0315C
...
3
Reflector Set TAC-B018-2300C
...
4
Plastic Bushing TAC-B017-0214
...
5
Nozzle Hose TAC-B225-0614
...
6
Wheel Shaft TAC-B010-0100
...
7
E-Clip 5mm TAC-A732-0300
...
8
Rear Wheel TAC-B010-1731
...
9
Screw TAC-A732-7400
...
10
Screw TAC-A732-8314
...
11
Nozzle Inlet Tube TAC-B017-0213
...
12
Screw M4x16 TAC-A732-5300
...
13
Light Bulb TAC-A350-0000
...
14
Lamp Holder TAC-A018-0800D
...
15
Furniture Guard TAC-B017-0431
...
16
Nozzle Fillet TAC-B017-0814
...
17
Screw TAC-A732-0600
...
18
Shoulder Washer TAC-B732-0000
...
19
Foam Pad Light Socket TAC-B015-1800
...
20
Plastic Baseplate TAC-B015-0214
...
21
Metal Cladding TAC-B015-1004
...
22
Base Plate Clip Spring TAC-B015-0900
...
23
Base Plate Clip TAC-B015-0814
...
24
Base Plate Lock Stud TAC-B015-0305B
...
25
Base Plate Assembly TAC-D015-0800
...
26
Carpet Floor Switch Assembly TAC-D017-3800
...
27
Simplicity 6000 Belt TAC-B014-0714
...
28
Agitator Packing Seal TAC-B021-0100
...
29
Pedal Shaft TAC-B020-0500
...
30
E-Clip 4mm TAC-A732-0200
...
31
Nylon Axle Washer TAC-A328-0100B
...
32
Pedal TAC-B020-0614B
...
33
Pedal Spring TAC-B020-0700
...
34
Pedal Frame TAC-B020-0800
...
35
Foot Pedal Assembly TAC-D020-0600
...
36
Roller Frame Shaft TAC-B008-0100
...
37
Roller Frame Wheel TAC-B010-1813
...
38
Frame Shaft Spring TAC-B008-0500
...
39
Nozzle Roller Frame TAC-B008-0400
...
40
Skid Plate Left TAC-B008-0214
...
41
Skid Plate Right TAC-B008-0314
...
42
Skid Plate Screw TAC-A732-0500
...
43
Washer TAC-B017-2500
...
44
Screw TAC-A732-7906
...
45
Roller Frame Assembly TAC-D010-1813

Simplicity SYMP.4

...
...
xx
Strain Relief TAC-B333-3014B
...
xx
Upper Cord Hook w/Power Cord (f/replacment) TAC-D431-1400
...
1
Handle Right(Handle Tube #18 or Heavy Duty Handle Kit #24, must be purchased in order to replace handle) TAC-B484-0214B
...
2
Handle Left(Handle Tube #18 or Heavy Duty Handle Kit #24, must be purchased in order to replace handle) TAC-B484-0414B
...
3
Screw TAC-A732-8314
...
4
Power Cord TAC-D434-1700B
...
5
E-Clip TAC-A732-2400
...
6
Upper Cord Hook Mount TAC-B431-6614
...
7
Upper Cord Hook Mount Screw TAC-A430-0500C
...
8
Hose Carrier TAC-B430-0214
...
9
Upper/Lower Cord Hook TAC-B430-0114
...
10
Upper Cord Hook Spring TAC-B430-0200
...
11
Upper Cord Hook Washer TAC-A430-0405
...
12
Upper Cord Hook Screw TAC-A430-0600C
...
13
Upper Cord Hook Assembly TAC-D431-5614
...
14
Lower Cord Hook Screw TAC-A430-0900B
...
15
Handle Bolt TAC-A432-0405B
...
16
Handle Mount Back TAC-B431-6114
...
17
Handle Mount Front TAC-B431-6014
...
18
Handle Tube TAC-B431-6200B
...
19
Handle Harness TAC-B431-5700
...
20
Indicator Light TAC-A328-1600
...
21
Switch On/Off TAC-A328-1500
...
22
Wire Connector Md TAC-B123-0100
...
23
Handle Assembly Complete TAC-D384-2414B
...
24
Heavy Duty Handle Kit w/6 screws For Replacement TAC-D431-1800

Simplicity SYMP.4

...
...
1
Dust Compartment TAC-D224-0414
...
2
Tool Clip TAC-B226-0414
...
3
Tool Clip Screw TAC-A732-7300
...
4
Crevice Tool TAC-B226-0314B
...
5
Tool Shelf TAC-B226-0514
...
6
Screw TAC-A732-8314
...
7
Hose Connector TAC-B225-0614
...
8
Upholstery Tool Retainer Clip TAC-B626-1414
...
9
Upholstery Tool TAC-B226-0114
...
10
Slide On Upholstery Tool TAC-B226-0614
...
11
Wand Assembly TAC-C626-1214

Simplicity SYMP.4

...
...
xx
White Crimped Brush Strip 4pack TAC-SBSW-4C
...
xx
Natural Brush Strips 4 pack TAC-SBSN-4C
...
1
Agitator Assembly Complete TAC-D012-2700
...
2
Rubber End Cover Left TAC-B012-0214
...
3
Metal End Cap Left TAC-B012-2300
...
4
Agitator Bearing Felt Cover TAC-B012-0600
...
5
Agitator Bearing TAC-B012-1400
...
6
Agitator Bearing Holder Assembly C012-1500
...
7
Agitator Brush Strip Nylon TAC-B012-2400B
...
8
Clutch Rubber Pad Assembly TAC-C012-0400
...
9
Agitator Compression Spring TAC-B012-1700
...
10
Agitator Pulley Clutch TAC-C012-0700
...
11
Inside Metal Cam TAC-B012-1414
...
12
Outside Cam TAC-B012-1514
...
13
Metal End Cap Right TAC-B012-1100
...
14
Spring Pin TAC-B012-1200
...
15
Agitator Shaft TAC-B012-2200
...
16
Agitator Spring Clip TAC-A732-0400
...
17
Washer Adjustment Kit (Not shown) TAC-B40

Simplicity SYMP.4

...
...
xx
Diameter Motor Mount (Not shown) TAC-B113-1100B
...
xx
Motor Mount Seal Kit(f/Replacement) TAC-D121-0100
...
1
Back Motor Mount Seal TAC-B113-0700C
...
2
12 Amp 1 Stage Motor TAC-D113-5100
...
3
Motor Mount Front TAC-B113-0614C
...
4
Motor Sound Suppressor TAC-B123-1900
...
5
Lead Wires (for replacement) TAC-C133-0100
...
6
Zip Tie (for replacement) TAC-A732-0100
...
7
Carbon Brushes(f/replacement) TAC-A113-2900
...
8
Metal Pivot Sleeve TAC-B123-1300
