product name

Sebo 91620AM Air Belt E2 Turbo Dark Blue

Model: Air Belt E2

Save
 Part Not Listed?Part Not Listed?
product name

Sebo Air Belt E2

...
...
1
Bottom casing, dark blue 8335DBER
...
2
Castor front, gray-black 8275GSER
...
3
Castor rear, gray-black 8276GSER
...
4
Cover exhaust air filter, dark blue 8249DBER
...
5
Technic module incl. pos. 6+7 8230GSER
...
6
Bag holder 7045ER
...
7
Bolt 20 x 5/7 8053ER
...
8
Engine mount gasket 8212ER
...
9
Vac motor 120V 8349ER
...
10
Wire 8282ULER
...
11
Motor support 8045ER
...
12
Noise limiting cover 8220ER
...
13
Motor cover 8289ER
...
14
Cable rewind unit, AM plug 665631ER
...
15
Potentiometer pinion 8256ER
...
16
On/Off button E1, cpl. 8338ER
...
17
Printed circuit board 8291ER
...
18
Screw 4 x 14 01036ER
...
19
Screw STS 4 x 20 T20 01017ER
...
20
Microfilter box E - pre-motor filter and exhaust microfilter 8322AM
...
21
Filter bags E 8300AM
...
22
Top casing, dark blue 8328DBER
...
23
Top cover E1, inner part 8340ER
...
24
Filter cover 8224DBE2ER
...
25
Bumper 8237ER
...
26
AIRBELT, gray-black 8221AM01
...
27
Support 8213GSER
...
28
Crevice nozzle 8066GS
...
29
Upholstery nozzle 8310GS
...
30
Hose cpl. incl. handle 8310
...
31
Hose E1 8314
...
32
Handle grip, cpl. 6300GS
...
33
Retaining ring 6303GS
...
34
Telescopic tube 6237ER
...
35
Fitting neck 1736GS
...
36
Release button, cpl. 1735ER
...
37
Locking mechanism 6238ER
...
38
Sliding knob 6425ER
...
50
Kombi nozzle, grey-black 1397GS
...
51
Turbo nozzle TT-C 6780GS
...
52
Parquet brush 6391DA
...
53
Dusting brush & clip 6728ER
...
...
...
