MTD Pro Snow Throwers 31AE6LFH718 (2005)

Model: 31AE6LFH718 (2005)

Back To Assemblies

Save Part Not Listed?
product name

Chute Assembly

...
...
1
Clean Out Tool MTD-931-2643
...
2
3 BLADE 12" IMPELLER MTD-684-04057C-0637
...
3
Hex Screw, 3/8-16, 1.75, Gr5, Std MTD-710-0347
...
4
Bolt, Carriage, 5/16-18, .750 Gr1 MTD-710-0451
...
5
Screw, Carriage, 1/4-20, .75, Gr5 MTD-710-0703
...
6
Screw, Self-tapping, 5/16-12, 0.750 MTD-710-0726
...
7
Nut, Flange Lock, 5/16-18, Grf, Nylon MTD-712-04063
...
8
Nut, Flange Lock, 1/4-20, Grf, Nylon MTD-712-04064
...
9
Nut, Flange Lock, 3/8-16, Grf, Nylon MTD-712-04065
...
10
Inter. Cotter Pin MTD-714-0149B
...
11
Cable, Tie, 3/16 x .05 x 7.4 MTD-725-0157
...
12
Nut, Push-on, .25 Dia. MTD-726-04012
...
13
CHUTE ADAPTER MTD-731-04705D
...
14
Spring, Extension, .38 OD x 3.6 MTD-932-0611
...
15
Washer, Wave, .625 x.885 x.015 MTD-736-0174
...
16
CLEANOUT TOOL MOUNTING CLIP MTD-731-11421
...
17
SHOULDER SCREW .498 DIA x .340 MTD-738-0143
...
18
Shld. Bolt .625 Dia. x .170 Lg. MTD-738-0281
...
19
Pin, Shear, .25 x 1.50, Gr2 MTD-738-04124A
...
20
Bearing, Hex Flange x .75 ID MTD-941-0245
...
21
Bearing, Ball, .75 ID x 1.85 OD MTD-941-0309
...
22
Idler Pulley, Flat 2.75 OD MTD-756-04224
...
23
BEARING HOUSING 1.85 ID MTD-790-00075B
...
24
AUGER IDLER BRACKET MTD-790-00080D
...
25
30" GEARBOX ASSEMBLY MTD-918-04165B
...
26
30" AUGER HOUSING MTD-684-04080
...
27
AUGER SPIRAL (LH) MTD-684-04107A
...
28
AUGER SPIRAL (RH) MTD-684-04108A
...
29
Cotter Pin, Bow-Tie MTD-714-04040
...
30
Spacer, 1.25 OD x .75 ID x 1.00 MTD-731-04870
...
31
Washer, Flat, .76 x 1.49 x .06 MTD-736-0188
...
32
Shear Pin, .25 x 1.50, Gr2 MTD-738-04124A
...
33
FLANGE BUSHING MTD-741-0493C
...
34
Housing, Bearing, 1" Hex MTD-790-00087A-0637
...
35
Plate, Shave, 2.25 x 29.66 MTD-790-00119
...
36
Bolt, Carriage, 5/16-18, 1.0 MTD-710-04071
...
37
WING NUT KNOB MTD-720-04032
...
38
UPPER CHUTE (W/LBL MANUAL TILT) MTD-731-04426C
...
39
Chute, Keeper Flange MTD-731-04869A
...
40
Chute, Lower, 5.0 Diameter MTD-731-04912B
...
41
Fl-Wash. .344" I.D. MTD-736-0159
...
42
Bushing, Plastic, .380 MTD-941-0475
...
43
Bracket, Chute Crank MTD-784-5647-0637
...
44
Shoe, Slide MTD-784-5580
...
45
Housing, Auger, RH Reduced MTD-918-0123A
...
46
Housing, Auger, LH Reduced MTD-918-0124A
...
47
Oil Seal 3/4" I.D. MTD-721-0179
...
48
Bearing, Flange, .75 ID x 1.00 OD x .59 MTD-741-0662
...
49
Screw, Self-tapping, 1/4-20, 0.750 MTD-710-0642
...
50
Auger Axle, 30" MTD-711-04282A
...
51
Key, Hi-pro 3/16 x 5/8 MTD-914-0161
...
52
Pin, Dowel, .25 OD x 1.2 MTD-715-04021
...
53
Shaft, Worm .75 OD MTD-917-04126
...
54
WORM GEAR 20T MTD-917-04861
...
55
Collar, Thrust MTD-718-04071
...
56
Plug, 1/4 x .437 MTD-721-0325
...
57
Seal, Oil, .75 x 1 x .131 MTD-721-0327
...
58
Fl-Wash. .76" I.D. x 1.5" O.D. x .030" Thk. MTD-736-0351
...
59
Washer, Flat, .51 x 1.12 MTD-736-3084
...
60
Bearing, Flange, .75 ID x 1.00 OD x .925 MTD-741-0663
...
61
Auger Clutch Cable, 44.75" MTD-946-0897
...
62
Bearing, Flange, .75 x 1.00 x .975 MTD-741-0661B
...
63
Bolt, Carriage, 5/16-18, 1.0 Gr1 MTD-710-0276
