Hex Bolt 1/4-20 x .50" Lg. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-910-0289
24
Shoulder Bolt .312 Dia. x .18 Lg. Special
MTD-738-0704
Hex Nut 1/4-20 Thd. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-912-0287
L-Wash. 1/4" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0329
Spacer .513" I.D. x .703" O.D. x .69" Lg.
MTD-748-0190
?63
Lock Wash. 5/16" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0119
HEX NUT 5/16-18 For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-712-3010
Cotter Pin 1/8" Dia. x 1.00" Lg. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-714-0115
Hex Bolt 1/4-20 x 1.25" Lg. w/Patch For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-1062
2
L-Wash. 1/4" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-726-0329
Hex Nut 1/4-20 Thd. Not Part of Transmission Complete; For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-912-0287
42
SPRING WASHER BELL Not Part of Transmission Complete
MTD-736-0270
43
L-Wash. 1/4" I.D. Not Part of Transmission Complete; For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0329
44
S.P. Cable Not Part of Transmission Complete
MTD-946-0710A
45
S.P. Belt Guard Not Part of Transmission Complete
MTD-747-0549
