LG WG1804R.AWYAWMT

Model: WG1804R.AWYAWMT

Save Part Not Listed?
product name

Main

...
...
35211A
Tube Assembly, Suction Single L-G-5211A10247B
...
130410
Base Asm. L-G-3041A30002B
...
130910
Cabinet L-G-3091AR6057A
...
135312
Front Grille Assembly L-G-3531A11002B
...
135313
Inlet Grille L-G-3530A10189A
...
146812
Ac Motor L-G-2H01102K
...
147581
Vane, Horizontal L-G-5990A20032A
...
152302
(15232) Filter Assembly,air Cleaner L-G-5231AR6159G
...
249950
Control Box Assembly, Single L-G-4995A20286R
...
263230
Thermistor L-G-6323A20003D
...
264110
Ac Power Cord Assembly L-G-2H00677Q
...
267110
Remote Controller Assembly L-G-6711A90024S
...
268711A
Control Board L-G-6871A20195A
...
268711B
Control Board L-G-6871A20188J
...
346811
Motor L-G-4681A20081V
...
349001
Damper L-G-4900AR7265B
...
349480
Orifice L-G-4948A20014A
...
349600
Mount L-G-4960AR1596A
...
352111
Tube L-G-5211AR7059A
...
352113
Tube Assembly, Discharge Single L-G-5211A20805A
...
352390
Air Guide L-G-5239A20001R
...
354210
Evaporator Assembly, Frist L-G-5421A90021C
...
359012
Turbo Fan L-G-5901A20009A
...
550140
Room Air Conditioner Compressor Grommet L-G-4H00982C
...
554030
Condenser Assembly, First L-G-5403A20112A
...
554160
Compressor L-G-2520UMGK2AA
...
559011
Room Air Conditioner Condenser Fan Blade L-G-5900AR1330A
Schematic Image Zoomed
