LG LSU090HSV5.AK6GEUS

Model: LSU090HSV5.AK6GEUS

Save Part Not Listed?
product name

Outdoor Unit

...
...
HNMC11
Harness,multi L-G-EAD62145817
...
263EAZ
Thermistor Assembly,ntc L-G-EBG61325812
...
263HZZ
Thermistor Assembly,ntc L-G-EBG61285804
...
263RZZ
Thermistor Assembly,ntc L-G-EBG61106852
...
2687M
Pcb Assembly,main L-G-EBR79393314
...
55211G
Tube Assembly,expansion L-G-AJR75104008
...
55220B
Valve,expansion Body L-G-MJX63991801
...
135520
Cover L-G-MCK56985610
...
137213
Panel Assembly,side L-G-AGL68979414
...
148001
Supporter L-G-MJH56985703
...
237202
Panel,front L-G-MGC56983325
...
237204
Panel,side L-G-MGC56985308
...
249300
Holder,sensor L-G-MEG63259001
...
352111
Tube Assembly,connector L-G-AJR74128501
...
352113
Tube Assembly,connector L-G-AJR74128601
...
359014
Fan Assembly,propeller L-G-ADP74253301
...
430410
Base Assembly,outdoor L-G-AAN68977832
...
435301
Grille,discharge L-G-MDX63452301
...
435513
Cover Assembly,tubing L-G-ACQ68981126
...
437211
Panel Assembly,front(outdoor) L-G-AGL74875105
...
546710
Motor Assembly,dc,outdoor L-G-EAU57945708
...
549610
Bracket Assembly,motor(outdoor) L-G-ABA75269301
...
550140
Damper,compressor L-G-MCQ62508902
...
552112
Tube Assembly,condenser(in) L-G-AJR69388501
...
552116
Tube Assembly,reverse L-G-AJR75103104
...
552202
Valve,reverse L-G-5220AR3228X
...
552222
Valve,service L-G-MJX62451504
...
552232
Valve,service L-G-MJX42581405
...
554031
Condenser Assembly,bending L-G-ACG73867901
...
554160
Compressor Set,china L-G-TBZ37534501
...
561420
Solenoid L-G-6141A20017E
...
649950
Case Assembly,control(outdoor) L-G-ABQ75180621
...
661401
Coil,expansion L-G-EAP63107114
