LG LG505C

Model: LG505C

Save Part Not Listed?
product name

Main

...
...
1
Tape, Protection Slide L-G-MJN67680506
...
2
Tape, Protection Window L-G-MJN67757308
...
3
Window, Assy Lcd L-G-EBD61045504
...
4
Tape, Window Main (2) L-G-MJN67757201
...
5
Tape , Window Main (1) L-G-MJN67757101
...
6
Deco, Upper Cover L L-G-MCR64412501
...
7
Deco , Upper Cover R L-G-MCR64412601
...
8
Cover, Upper L-G-MCK66677808
...
9
Pad, (fpcb Sensor) L-G-MCQ66704501
...
10
Insert L-G-MICE0016901
...
11
Filter, (mic) L-G-MFBZ0028701
...
12
Mic Pad L-G-MCQ66825401
...
13
Keypad Assy Sub L-G-AEX73718508
...
14
Filter, (receiver) L-G-MFBZ0028805
...
15
Pad, Rcv Top L-G-MPBZ0338001
...
16
Lcd, Assy L-G-SVLM0039902
...
17
Receiver L-G-SURY0010122
...
18
Dome Sheet, Sub L-G-ADB73619101
...
19
Sub Pcb Assy L-G-SAJY0051403
...
20
Fpcb Assy L-G-SACY0118004
...
21
Tape, Lcd Conn L-G-MTAZ0373801
...
22
Insulator, Lcd Conn L-G-MIDZ0280101
...
23
Lcd Bottom Insulator L-G-MEV63951301
...
24
Pad, Lcd Conn L-G-MPBU0114201
...
25
Pad, (mic) L-G-MPBZ0338106
...
26
Tape Protection L-G-MJN67696801
...
27
Pad , (t/w Connector) L-G-MPBZ0338501
...
28
Pad, Lower Proximity L-G-MPBZ0365301
...
29
Hinge. Assy L-G-AHFY0004508
...
30
Cover, Lower L-G-MCK66701008
...
31
Screw Machine, Bind L-G-GMEY0010601
...
32
Cap, Screw L-G-MBL64922408
...
33
Tape, Protection Front L-G-MTAB0433301
...
34
Keypad Assy Main L-G-AKAC0020608
...
35
Cover Front L-G-MCJK0137908
...
36
Sheet, Front (2) L-G-MPBZ0338201
...
37
Tape, Main Connector L-G-MTAZ0372101
...
38
Sheet, Front (1) L-G-MPBZ0338401
...
39
Magent L-G-RAB32795201
...
40
Insert L-G-MICE0016902
...
41
Screw, Hinge L-G-GMEY0018101
...
42
Dome, Sheet Assy L-G-ADCA0120608
...
43
Pcb Assy Main L-G-SAFY0383104
...
44
Antenna, Sub L-G-SNMF0070401
...
45
Motor L-G-EAU61425901
...
46
Tape, Absorber L-G-MTAZ0373901
...
47
Can Assy, Shield L-G-ACKA0034701
...
48
Label L-G-MLAB0004801
...
49
Intenna, Main L-G-SNMF0080301
...
50
Speaker L-G-SUSY0028910
...
51
Pad, Speaker (2) L-G-MCQ66474101
...
52
Pad, Speaker L-G-MCQ66499501
...
53
Filter, Speaker L-G-MFBZ0033401
...
54
Button, (camera) L-G-MBJZ0046708
...
55
Cap, (multimedia) L-G-MCCZ0047708
...
56
Tape, Protection Key (camera) L-G-MBJZ0046908
...
57
Button , (volume) L-G-MBJZ0046908
...
58
Cap, (usb) L-G-MCCZ0047808
...
59
Tape, Protection Key (volume) L-G-MJN67707601
...
60
Button, (lock) L-G-MBJZ0046808
...
61
Tape, Protection Key (lock) L-G-MJN67707801
...
62
Gasket, Connector L-G-MDS63551701
...
63
Bracket, Connector L-G-MBFZ0060401
...
64
Tape, Bracket Connector L-G-MJN67667001
...
65
Pad, (camera) L-G-MPBZ0338601
...
66
Pad, Sub Intenna L-G-MPBZ0356101
...
67
Pad, (motor) L-G-MPBZ0338701
...
68
Sheet, Ear-Jack L-G-MHK63287705
...
69
Label Qualcomm L-G-MLAN0000604
...
70
Cover, Rear L-G-MCJN0130108
...
71
Tape, Deco Camera L-G-MTAA0233601
...
72
Window, Camera L-G-MWAE0067201
...
73
Deco, (camera) L-G-MDAY0091501
...
74
Cap, Ms L-G-MCCZ0047908
...
75
Tape, Protection Rear(1) L-G-MTAB0444601
...
76
Tape , Protection Rear(2) L-G-MJN67680401
...
77
Screw L-G-GMZZ0017701
...
78
Battery Cell L-G-SBPL0099701
...
79
Cover, Battery L-G-MCJA0123408
Schematic Image Zoomed
