LG LBN10551PS.APZCNA0

Model: LBN10551PS.APZCNA0

Save Part Not Listed?
product name

Main I

...
...
102A
Front Cover Assembly L-G-ACQ86325532
...
102C
Cap,cover L-G-MBL65998201
...
102B
Cover,front L-G-MCK68751010
...
103A
Handle,rear L-G-MEB61847007
...
103B
Handle,rear L-G-MEB61847008
...
108A
Drain Tray Assembly L-G-3391JQ2010A
...
109A
Refrigerator Cap Cover L-G-5006JQ3032A
...
200A
Freezer Door Assembly L-G-ADC74186313
...
201A
Freezer Door Foam Assembly L-G-ADD73518415
...
203A
Gasket Assembly,door L-G-ADX73591402
...
210A
Stopper,door L-G-MJB63150601
...
210B
Stopper,door L-G-MJB63170801
...
230A
Door Assembly,refrigerator L-G-ADC32822174
...
231A
Door Foam Assembly,refrigerator L-G-ADD73498846
...
233A
Gasket Assembly,door L-G-ADX73591403
...
281A
Hinge Assembly,upper L-G-AEH74276202
...
281B
Hinge Assembly,upper L-G-AEH74276201
...
281D
Cap,hinge L-G-5006JQ3012U
...
281E
Cover,hinge L-G-MCK67506810
...
281F
Cover,hinge L-G-MCK67506809
...
281H
Cap Assembly,decor Refrigerator L-G-ABN73880325
...
282B
Hinge Assembly,center L-G-AEH74158001
...
283B
Hinge Assembly,lower L-G-AEH74137802
...
304A
Cover Assembly,machinery(rear) L-G-ACQ76009101
...
407B
Capacitor,electric Appliance Film,radial L-G-EAE32501015
...
501A
Main Pcb Assembly L-G-EBR76347628
...
501F
Cover Assembly,pcb L-G-ACQ76174708
...
503A
Display Pcb Assembly L-G-EBR36495811
...
610E
Cover Sensor L-G-3550JQ2025A

Main Ii

...
...
104A
Supporter Assembly L-G-4981JQ3001A
...
104C
Supporter L-G-4980JQ3033A
...
105A
Refrigerator Drain Tube Assembly L-G-5251JQ3002A
...
106B
Leg Assembly L-G-4779JQ3002A
...
120A
Case Assembly,control Refrigerator L-G-ABQ74149301
...
120B
Case,control Refrigerator L-G-MBN63031802
...
120D
Cover,lamp L-G-MCK67400601
...
120E
Duct,insulation L-G-MCZ62873101
...
301A
Refrigerator Evaporator Assembly L-G-5421JQ0019A
...
303D
Harness Assembly L-G-6877JR3007E
...
307A
Refrigerator Compressor L-G-TCA30129802
...
308A
Refrigerator Compressor Start Relay L-G-6748C-0004D
...
309A
Overload Protect L-G-EAF61770715
...
310A
Ptc Cover L-G-MCK51763401
...
312A
Refrigerator Compressor Damper L-G-5040JQ3008B
...
314A
Stopper L-G-4J03277A
...
315A
Base Assembly,compressor L-G-AAN73069301
...
315B
Roller L-G-4580JQ3001B
...
315C
Common Pin L-G-1PZZJQ3017A
...
317A
Drier Assembly L-G-ADH69749102
...
318A
Holder,drier L-G-4930JQ3020D
...
319A
Tray,drip L-G-MJS61912301
...
319B
Tray Assembly,drip L-G-AJP73015502
...
319C
Guide,fan L-G-MEA62071201
...
323B
Condenser Assembly,wire L-G-ACG73924801
...
327A
Restrainer L-G-5072JQ3002B
...
328A
Damper,motor Support L-G-MCQ65884302
...
329A
Fan Assembly L-G-ADP73673901
...
329C
Fan Assembly L-G-ADP36665705
...
330B
Shroud Assembly,freezer L-G-AHV72970201
...
332A
Grille Asy,f L-G-3531JQ2001A
...
401A
Refrigerator Defrost Sensor L-G-4781JR2004C
...
401B
Led Assembly L-G-EAV61573111
...
404A
Refrigerator Dc Motor L-G-EAU60694522
...
405A
Bracket,motor L-G-MAZ62231901
...
405C
Refrigerator Damper Motor L-G-5040JQ2003B
...
411A
Power Cord Assembly L-G-EAD62427003
...
418A
Refrigerator Heater L-G-5300JR1006D
...
420A
Motor,dc L-G-EAU60694520
...
604F
Refrigerator Duct Cover L-G-3550JQ2046A

Main Iii

...
...
103E
Stopper,handle L-G-MJB63190801
...
125A
Refrigerator Ice Tray L-G-3390JQ2001A
...
136C
Tray Assembly,drawer L-G-AJP72975202
...
136E
Shelf Assembly,refrigerator L-G-AHT73754301
...
136D
Tray Assembly,drawer L-G-AJP72975302
...
136B
Tray Assembly,drawer L-G-AJP72975102
...
136A
Tray Assembly,drawer L-G-AJP72975002
...
151B
Tray Assembly,vegetable L-G-AJP73816309
...
154B
Cover,tray L-G-MCK67483101
...
154D
Roller Assembly L-G-AHJ73229901
...
154G
Roller L-G-MHA62513501
...
155A
Cover Assembly,tv L-G-ACQ86325403
...
235A
Tray,egg L-G-MJS62773801
...
241A
Basket,door L-G-MAN62769103
...
241C
Basket,door L-G-MAN62769003
