LG A-DMC36CA-1.ANWAHCI

Model: A-DMC36CA-1.ANWAHCI

Save Part Not Listed?
product name

Main (i)

...
...
W0CZZA
Room Air Conditioner Fan Motor Capacitor L-G-6120AR2194K
...
W0CZZB
Room Air Conditioner Fan Motor Capacitor L-G-6120AR2194F
...
W6631
Multi Harness L-G-EAD30651206
...
W6640A
Terminal Block 6p Fc L-G-4G00103A
...
W6640B
Terminal Block L-G-3H00390A
...
W6640C
Connector, Terminal Block L-G-4G00103C
...
55211G
Tube Assembly, Expansion L-G-AJR30127901
...
137213
Panel Assembly,side L-G-3721A20229A
...
148000
Supporter L-G-4980AP2517D
...
237202
Panel,front L-G-MGC61723602
...
263230D
Thermistor Assembly,ntc L-G-EBG61107013
...
268711B
Main Pcb Assembly L-G-6871A21318E
...
430411
Base Assembly, Weld (outdoor) L-G-AAN32562207
...
435301
Grille,discharge L-G-MDX61846301
...
435511
Cover Assembly,control(outdoor) L-G-ACQ33125306
...
435512
Cover Assembly,top(outdoor) L-G-ACQ32490309
...
437211
Panel Assembly,front(outdoor) L-G-AGL32571805
...
437212
Panel Assembly, Front (outdoor) L-G-3720AP1202L
...
447900
Barrier, Outdoor L-G-4760AP1216C
...
546810
Motor Assembly, Outdoor L-G-4681A10030C
...
548490
Accumulator L-G-4848A20006K
...
549610
Bracket Assembly,motor(outdoor) L-G-ABA73028801
...
552113
Tube Assembly, Condenser (out) L-G-AJR30109601
...
552114
Tube Assembly, Discharge (outdoor) L-G-5211A19011A
...
552115
Tube Assembly, Discharge (outdoor) L-G-5211A00034A
...
552117
Tube Assembly, Discharge (outdoor) L-G-5211A00033A
...
552203B
Valve,service L-G-MJX62451501
...
552203A
Valve,service L-G-MJX62472101
...
554031
Condenser Assembly, Bending L-G-5403A20044B
...
554160A
Compressor Set, Korea L-G-TBZ30130501
...
554160B
Compressor Set, Korea L-G-2520UTBK1AA
...
559010
Fan Assembly L-G-1A00195B
...
566000
Service Valve L-G-6600L000013
...
567480C
Thermistor, Ntc L-G-6323A20019C
...
649950
Case Assembly, Control (outdoor) L-G-ABQ30144401
...
661400
Solenoid L-G-6141A20018Z
