LG A-DMC24CA-1.ANWAHCI

Model: A-DMC24CA-1.ANWAHCI

Save Part Not Listed?
product name

Main (i)

...
...
W0CZZA
Room Air Conditioner Fan Motor Capacitor L-G-3A00988B
...
W6640B
Terminal Block L-G-3H00390A
...
W6640A
Connector, Terminal Block L-G-3A00093A
...
W6631
Single Harness L-G-6631A20155P
...
W49810
Supporter, Valve L-G-4980A20001B
...
W4810
Bracket L-G-3A01934B
...
W0CZZB
Room Air Conditioner Fan Motor Capacitor L-G-6120AR2194F
...
135500B
Cover L-G-MCK47976001
...
137213A
Side Panel Assembly L-G-1A00202F
...
137213B
Side Panel Assembly L-G-3A02284N
...
263230B
Thermistor Assembly,ntc L-G-EBG61107013
...
268711B
Main Pcb Assembly L-G-6871A21318D
...
349480
Orifice L-G-4948A20005A
...
349600
Motor Mount L-G-1A00206B
...
352113
Discharge Tube Assembly L-G-5211A29916A
...
430410
Base Assembly, Outdoor L-G-AAN73130003
...
435300
Grill, Rear L-G-MDX59045502
...
435301
Grille,discharge L-G-MDX61844501
...
435511
Cover Assembly L-G-3550AR2886C
...
435512
Cover Assembly,top(outdoor) L-G-ACQ73019503
...
437210
Panel Assy,f L-G-1A00197C
...
437211
Panel Assembly,front(outdoor) L-G-AGL32105602
...
447910
Barrier Assembly, Outdoor L-G-4791A30004H
...
546810
Motor Assembly, Outdoor L-G-4681A10030C
...
548490
Accumulator L-G-4848A20006C
...
550140
Room Air Conditioner Compressor Grommet L-G-4H00982E
...
552112
Tube Assembly, Condenser (in) L-G-5211A25715A
...
552113
Tube Assembly, Condenser (out) L-G-5211A25716A
...
552117
Tube Assembly, Suction (outdoor) L-G-5211A29913A
...
552200
Valve, Expansion Body L-G-5220A90003B
...
552203A
Valve,service L-G-MJX62472001
...
552203B
Valve,service L-G-MJX62451501
...
554031
Condenser Assembly,bending L-G-ACG73547302
...
554160
Compressor Set, Korea L-G-2520UGKK2AA
...
559010
Fan Assembly L-G-1A00195B
...
566000
Service Valve L-G-6600L000013
...
567480C
Thermistor,ntc L-G-6323A20028B
...
649950
Case Assembly, Control (outdoor) L-G-4995A10112M
...
661400
Solenoid L-G-6141A20018Z
