Kenmore BC4026 Bagged Canister Vacuum Blue

Model: BC4026

Save Part Not Listed?
product name

Kenmore BC4026

...
...
1
Lower Body KC03AEEJZV06
...
2
Dust Cover 591014103
...
3
Canopy 591014104
...
4
Tool Storage Cover 591014105
...
5
Tool Storage Cover 591014106
...
6
Furniture Guard KC31AEEJZV06
...
7
Caster Supporter KEN-KC34CEEJZV06
...
8
Caster Unit KEN-4370691
...
9
Body Pad KC03GDWCZ000
...
10
Wheel 591014107
...
11
Valve Grommet KC45KEEJZV06
...
12
Motor Safety Filter (Retail No. 20-81002) KEN-8175139
...
13
Motor Support Rubber KC02FDJHZ000
...
14
Fan Motor Unit KEN-KC92FEAYZ000
...
15
Motor Support Rubber KC03FEEJZ000
...
16
Noise Suppressor 8174919
...
17
Noise Absorber KC10GEEJZ000
...
18
Upper Body KC02AEEJZ000
...
19
Adapter Tube KC62PEEJZ000
...
20
Indicator Window KC08MEEJZ000
...
21
Indicator Light Switch KC96MEEJZ000
...
22
Pcb B Unit KEN-KC85VEEJZ000
...
23
Motor Shield KC58FEEJZ000
...
24
Filter Supporter KC32FEEJZV06
...
25
Exhaust Filter 591014101
...
26
Filter Cover KEN-KC41KEEJZV06
...
27
Latch KEN-KC15KEEJZMUQ
...
28
Cord Reel Assembly 591016108
...
29
Hepa Bag (Retail No.20-53291(2-Pack) & 20-53292(6-Pack)) KEN-KC16KDPTZ000
...
30
Receptacle Assy 3 Wire KC90EEEJZV06
...
31
Spring,Bag Mount KS706024
...
32
Packing,Inlet(Bag) KEN-4370688
...
33
Dust Bag Supporter(Mount) KC10KEEJZR0K
...
34
Dust Bag Supporter Packing 591015106
...
35
Dust Cover Latch KC01DEEJZMUQ
...
36
Tool Caddy KC66PEEJZV06
...
37
Lid Holder Bracket KC44HEEJZV06
...
38
Lis Shaft KC80HEEJZV06
...
39
Leaf Spring KC24DEEKZ000
...
40
Spring KC23DEEMZ000
...
41
Button(Cord Reel) KC46NEEJZV06
...
42
Button(Tool Released) KC64NEEJZV06
...
43
Lever Guide KC89LEEJZV06
...
44
Spring KC65DEEKZ000
...
45
Spring(Lid) KEN-KC18DEEJZ000
...
46
Indicator/Window KC08MEEKZ000
...
47
Ornamental Plate KC21TEDCZ000
...
48
Floor Brush KEN-KC83QEEJZV06
...
49
Dusting Brush KEN-KC94QDWCZV06
...
50
Crevice Tool KEN-KC60REEJZV06
...
51
Pet Powermate 591016109
...
52
Screw KEN-4368563
...
53
Label KC24ZEEJZ000
...
54
Black Lead Wire KC85GEEJZ000
...
55
White Lead Wire KC85WEEJZ000
...
56
Wire Nut KS4154460
...
57
Use & Care Guide 591014109

Kenmore BC4026

...
...
1
Window Height Adjust 4369687
...
2
Nozzle Cover 591014110
...
3
Floor Nozzle Upper KC02REEJZVU6
...
4
Secondary Filter Foam 4370713
...
5
Screw KEN-4368563
...
6
Furniture Guard KC10AEEJZV06
...
7
Agitator Cover KC01QEEJZV06
...
8
Screw 4370699
...
9
Powermate Agitator Assembly 591005128
...
10
Indicator Block Assembly KEN-KC83MAKSZV06
...
11
Nozzle Wheel Overmold KEN-KC99CEEJZV06
...
12
Nozzle Wheel Washer 591004168
...
13
Nozzle Wheel Axle KC02CEEJZ000
...
14
Floor Nozzle Lower KC03REEJZV06
...
15
Belt (Retail No. 20-53013) KC28SBZTZ000
...
16
Screw 4369085
...
17
Wire Nut KS4154460
...
18
Front Axle Assembly KEN-591004173
...
19
Motor Gasket KS747156
...
20
Nozzle Motor KEN-KC90FEEJZ000
...
21
Motor Adjustment Spring KS742002
...
22
Metal Bracket KS705093
...
23
Lifter KEN-4370726
...
24
Overload Protector KEN-KC76KDGSZ000
...
25
Swivel Cap KEN-KC25QAKT4V06
...
26
Handle Release Pedal KEN-KC47AEEJZMUQ
...
27
Swivel Seal KEN-KS742019
...
28
Nozzle Holder KC76PEEJZV06
...
29
Nozzle Support B KC78PEEJZV06
...
30
Nozzle Plug Wire Unit 2-Pin KEN-KC67VDKNZV06
...
31
Sensor Cover A KC69QEEJZV06
...
32
Sensor Cover B KC68QEEJZV06
...
33
Spring(Button) 591004188
...
34
Foot Pedal Quick Release KC70QEEJZMUQ
...
35
Screw 4370280
...
36
Locking Clip KC82DEEJZV06
...
37
Floor Brush 591014102

Kenmore BC4026

...
...
1
Switch Case Deco 591014111
...
2
Actuator KC02UDKMZM0Q
...
3
Slide Supporter KC53KDKMZV06
...
4
Actuator KC02UEEKZM0Q
...
5
Pcb Assembly KEN-KC87GEEJZ000
...
6
Screw 4369085
...
7
Handle-Upper KC01BDKNZV06
...
8
Button(Release) KEN-KC13DDKNZMUQ
...
9
Spring KC65DDKNZ000
...
10
Curved Wand KEN-KC30PDKNZV06
...
11
Packing KC04RATMZ000
...
12
Terminal Cover KC45EDKMZV06
...
13
Handle-Lower KC64BEEJZV06
...
14
Lead Wire-Blue KC41GDKNZ000
...
15
Hose KEN-8192774
...
16
Hose Connection Cover KEN-4370325
...
17
Connection Pipe Assembly KC92PDXEZV06
...
18
Hose Assembly 591014112

Kenmore BC4026

...
...
1
Extension Wand Assembly KEN-KC99PEEJZV06
...
2
Connector(Upper Wand) KEN-591004211
...
3
Wand Pipe(Upper) KC05RDKNZ000
...
4
Wire Positioner Unit KC40EDKNZV06
...
5
Screw 591016114
...
6
Slide Supporter KEN-KC53KDKNZV06
...
7
Pipe Ring KEN-KC47PDKNZ000
...
8
Supporter(Guide) KEN-KC78ZDKNZ000
...
9
Extension Wand(Lower) KEN-KC48PDKNZ000
...
10
Locking Clip KEN-KC82DDKNZ000
...
11
Extension Wand Holder KEN-KC55PDKNZV06
...
12
Button Extension KEN-KC77FDKNZM0H
...
13
Spring KC65DDKNZ000
...
14
Rear Cover KC01LDKNZV06
...
15
Cable Assembly Lower KEN-KC97UDKNZ000
...
16
Flat Cable A Unit KC65VDKNZ000
...
17
Connection Wand(Lower) KC27HDKNZV06
...
18
Button(Release) KEN-KC13DDMMZVU4
...
19
Holder Button KC11DDKNZV06
...
20
Cover(Lower Wand Cuff) KC22QEEJZV06
