Kenmore 116.28612790 Canister Vacuum

Model: 116.28612790

Save Part Not Listed?
product name

Kenmore 116.28612790

...
...
xx
Label, Wiring Dlagram LIT4369364
...
xx
Instruction, Sheet LIT4369642
...
xx
Manual, Owner'S LIT4370576
...
xx
Repair Parts List LIT4370602
...
1
Padel, On Off 4369308
...
2
Tie Cable 596702
...
4
Relay, Motor 4152600
...
6
Wall, Bulkhead 4370653
...
7
Cap, Cord Cover 4153294
...
8
Seal, Impeller 4370589
...
11
Filter, Motor (Rear) 4370590
...
12
Seal, Motor 4370654
...
13
Motor, Fan 4370604
...
14
Brush, Motor (2) 4370655
...
15
Spring, Cord Button 744258
...
16
Screw, 8-18 X 3/4 (4) 4148999
...
17
Cover, Canopy 4370652
...
20
Wheel, Rear 4370555
...
21
Base 4370552
...
22
Filter, Safety KEN-4152969
...
23
Bumper 4155588
...
24
Harness, Receptacle 4370553
...
25
Pin, Caster Retainer 706884
...
26
Connector, Wire (3) 4154460
...
27
Caster, Swivel 4369683
...
28
Filter, Electrostatic KEN-4370059
...
29
Hood 4370558
...
30
Latch, Hood 4155627
...
31
Bag, Dust Sears No.2050558, Available At Any Sears Retail Or Catalog Store 4156187
...
32
Mount, Bag KEN-4369956
...
33
Gasket, Port 706017
...
34
Spring, Bag Mount 706024
...
35
Insert, Strike 4370318
...
37
Wheel, Caster 4369684
...
40
Indicator Unit 4370367
...
44
Grip, Handle 4155620
...
46
Screw, #10 4368879
...
47
Bracket 4156363
...
48
Packing, Indicator 4368704

Kenmore 116.28612790

...
...
1
Hose 4370560
...
2
Swivel Assembly KEN-4370563
...
3
Wand, Upper KEN-4370473
...
4
Label, Handle 4370566
...
5
Release, Quick 4153400
...
6
Adapter, Hose KEN-4370325
...
7
Handle KEN-4370663
...
8
Tube, Center KEN-4370612
...
9
Control, Suction 4370562
...
10
Harness, Wiring KEN-4370561
...
11
Slide, Switch 4370567
...
12
Switch, 3 Position KEN-4369108
...
13
Spring, Wand Lock 4152093
...
14
Wand, Lower KEN-4369395
...
15
Brush, Floor KEN-4370358
...
16
Tool, Crevice KEN-4370333
...
17
Brush, Fabric 4370334
...
18
Brush, Dusting KEN-4370559
...
19
Spring, Wand Lock 725419
...
20
Screw 4368879

Kenmore 116.28612790

...
...
xx
Label, Wiring Diagram LIT747155
...
4
Housing Blub (Includes No. 55) 4370336
...
5
Screw 8-18 X 1-7/8 (2) 681550
...
6
Nozzle (Incudes No. 7) 4370579
...
7
Bumper 4155587
...
8
Foot Pedal 4153195
...
10
Swivel 4153196
...
11
Swivel Seal (2) 742019
...
12
Pad, Foot Pedal 4370577
...
13
Indicator Lever 747287
...
14
Indicator Cam 747291
...
15
Indicator Block 742015
...
16
Spring Assist 725775
...
17
Brush Assembly 742454
...
18
Washer, Metal (12X1/2) (2) MSC-681424
...
19
Bearing And Housing Assembly (2) (Includes Illus. 18) 743395
...
20
Litter 742013
...
21
Handle Release 4370578
...
22
Overload Protector 742332
...
23
Wire Connector 4368522
...
24
Roller, Rear (2) 4370364
...
25
Rear Axel (2) 742006
...
26
Base 4369752
...
27
Front Axel Assembly 744029
...
28
Swivel Cap 4370340
...
29
Washer, Thrust 722909
...
30
Washer 725635
...
31
Catch Indexing 722955
...
32
Ratchet Catch 742016
...
33
Screw Type 25 #6 Pan (2) 681605
...
34
End Brush Tuffed 742509
...
35
Brush Sprocket 742506
...
36
Brush Sprocket Flange 742031
...
38
Beater Brush (2) 742030
...
39
Bar, Beater 742029
...
40
Screw 8-18X5/8(2) 681297
...
41
Motor Bridge 705093
...
42
Belt, Cogged, Sears No. 20-5285, Available At Any Sears Retail Store. 742024
...
43
Motor 4370112
...
44
Motor Adjustment Spring 742002
...
45
Lens, Height Adjuster 4369687
...
46
Extension, Button 4370580
...
47
Socket, Bulb 747096
...
48
Cord And Plug Hose Assembly 4370342
...
51
Bulb, Light (15 Watt) Sears No. 20-5240, Available At Any Sears Retail Store. 4370018
...
55
Lens Light 747286
...
56
Cover, Plug Housing 4153194

Kenmore 116.28612790

...
...
1
Nozzle 4370582
...
2
Release, Button 4152444
...
3
Screw 4152468
...
4
Tube, Locking 4368508
...
5
Base 4370583
...
7
Belt, Sears No. 20-5271, Available At Any Sears Retail Or Catalog Store. KEN-4368510
...
8
Cap, Dowel End 4152440
...
9
Dowel Assembly 4368511
...
10
Dowel,Shaft 4152439

Kenmore 116.28612790

...
...
1
Bracket, Contact Block 4152380
...
2
Main Body 4152226
...
3
Spring And Keeper 4149917
...
4
Flange 4149336
...
5
Pawl (2) 700713
...
6
Bracket, Speed Control 4155598
...
7
Governor Weights (2) 4149369
...
8
Hub 4369312
...
9
Power Cord 4370581
...
10
Contact Disc Asm 4152682
...
11
Screw (2) 595294
...
12
Screw 780343
...
13
Cord Reel Assembly 4370556
