Husqvarna YTH 2348 (917289570) (2010-04) Ride Mower

Model: YTH 2348 (917289570) (2010-04)

Back To Assemblies

Save Part Not Listed?
product name

Briggs Engine Image 3

...
...
1
Cylinder Assembly HUS-793564
...
2
Bushing/Seal Kit (MagnetoSide) HUS-499585
...
3
Seal-Oil (Magneto Side) Included in Engine Gasket Set, Key. No. 358 HUS-391086S
...
4
Sump-Engine HUS-796230
...
5
Head-Cylinder (Cylinder #1) HUS-796231
...
5A
Head-Cylinder (Cylinder #2) HUS-796232
...
7
Gasket-Cylinder Head Included in Engine Gasket Set, Key. No. 358, Included in Valve Gasket Set, Key No. 1095 HUS-693997
...
8
Breather Assembly HUS-792185
...
9
Gasket-Breather (Liquid Gasket and The Breather Gasket Are Interchangeable) Included in Engine Gasket Set, Key. No. 358 HUS-690937
...
10
Screw (Breather Assembly) HUS-697551
...
11
Tube-Breather HUS-792184
...
12
Gasket-Crankcase Included in Engine Gasket Set, Key. No. 358 HUS-697227
...
13
Screw (Cylinder Head) HUS-793988
...
15
Plug-Oil Drain HUS-690946
...
16
Crankshaft HUS-796540
...
20
Seal-Oil (PTO Side) Included in Engine Gasket Set, Key. No. 358 HUS-795389
...
22
Screw (Crankcase Cover/Sump) HUS-694966
...
23
Flywheel HUS-691053
...
24
Key-Flywheel HUS-222698S
...
25
Piston Assembly (Standard) HUS-792023
...
xx
Piston Assembly (020" Oversize) HUS-792072
...
26
Ring Set (Standard) HUS-793561
...
xx
Ring Set (.020" Oversize) HUS-792073
...
27
Lock-Piston Pin HUS-690975
...
28
Pin-Piston HUS-696581
...
29
Rod-Connecting HUS-699699
...
32
Screw (Connecting Rod) HUS-690976
...
33
Valve-Exhaust HUS-697576
...
34
Valve-Intake HUS-792200
...
35
Spring-Valve (Intake) HUS-694865
...
36
Spring-Valve (Exhaust) HUS-694865
...
40
Retainer-Valve HUS-690964
...
42
Keeper-Valve HUS-499586
...
45
Tappet-Valve HUS-690977
...
46
Camshaft HUS-790562
...
48
Short Block HUS-698172
...
50
Manifold-Intake HUS-695241
...
51
Gasket-Intake Included in Engine Gasket Set, Key. No. 358; Included in Valve Gasket Set, Key No. 1095; Included in Carburetor Overhaul Kit, Key, No. 121 HUS-795123
...
51A
Gasket-Intake Included in Engine Gasket Set, Key. No. 358; Included in Valve Gasket Set, Key No. 1095; Included in Carburetor Overhaul Kit, Key, No. 121 HUS-690950
...
53
Stud (Carburetor) HUS-690951
...
54
Screw (Intake Manifold) HUS-699816
...
73
Screen-Rotating HUS-494439
...
74
Screw (Rotating Screen) HUS-698425
...
75
Washer (Flywheel) HUS-691056
...
95
Screw (Throttle Valve) HUS-690718
...
98
Kit-Idle Speed HUS-699721
...
104
Pin-Float Hinge Included in Carburetor Overhaul Kit, Key, No. 121 HUS-694918
...
105
Valve-Float Needle Included in Carburetor Overhaul Kit, Key, No. 121 HUS-698537
...
108
Valve-Choke HUS-699723
...
117
Jet-Main (Standard) (Left) HUS-791501
...
117A
Jet-Main (Standard) (Right) HUS-791502
...
118
Jet-Main (High Altitude) (Left) HUS-695415
...
118A
Jet-Main (High Altitude) (Right) HUS-843099
...
121
Kit-Carburetor Overhaul HUS-792455
...
125
Carburetor HUS-796259
...
130
Valve-Throttle HUS-690993
...
131
Kit-Throttle Shaft HUS-499805
...
133
Float-Carburetor HUS-699724
...
135
Tube-Fuel Transfer HUS-699729
...
137
Gasket-Float Bowl Included in Carburetor Overhaul Kit, Key, No. 121 HUS-690994
...
141
Kit-Choke Shaft HUS-796228
...
142
Nozzle-Carburetor HUS-699726
...
146
Key-Timing HUS-690979
...
150
Gasket-Nozzle HUS-690995
...
160
Retainer-Solenoid (Brass) HUS-699727
...
163
Gasket-Air Cleaner HUS-691001
...
177
Seal-O Ring (Dipstick) HUS-691031
...
186
Hose-Connector (Oil Drain Hose) HUS-796532
...
187
Line-Fuel (Cut to RequiredLength) HUS-791766
...
188
Screw (Control Bracket) HUS-697551
...
192
Adjuster-Rocker Arm HUS-690083
...
197
Screw (Back Plate) HUS-697820
...
209
Spring-Governor (Yellow/Black) HUS-796224
...
211
Spring-Governed Idle (Orange) HUS-796225
...
212
Link-Throttle HUS-695238
...
216
Link-Choke HUS-796229
...
217
Spring-Choke Return HUS-695409
...
219
Gear-Governor HUS-793338
...
220
Washer (Governor Gear) HUS-690412
...
221
Cup-Governor HUS-841026
...
222
Bracket-Control HUS-796226
...
227
Lever-Governor Control HUS-796223
...
231
Screw (Choke Valve) HUS-690718
...
240
Filter-Fuel HUS-691035
...
250
Retainer-Breather HUS-690957
...
252
Collector-Oil HUS-690956
...
265
Clamp-Casing HUS-691024
...
267
Screw (Casing Clamp) HUS-792629
...
276
Washer-Sealing (Aluminum) HUS-794271
...
278
Washer (Governor Control Lever) HUS-792651
...
287
Screw (Dipstick Tube) HUS-691108
...
304
Housing-Blower HUS-796597
...
305
Screw (Blower Housing) HUS-691005
...
305A
Screw (Blower Housing) HUS-698336
...
305B
Screw (Blower Housing) (Blower Housing to Intake Elbow) HUS-790690
...
309
Motor-Starter HUS-497595
...
310
Screw (Starter Motor) HUS-690323
...
332
Nut (Flywheel) HUS-691059
...
333
Armature-Magneto HUS-691060
...
334
Screw (Magneto Armature) HUS-691061
...
337
Plug-Spark HUS-491055S
...
358
Gasket Set-Engine HUS-694012
...
385
Screw (Fuel Pump) HUS-697551
...
387
Pump-Fuel HUS-808656
...
404
Washer (Governor Crank) HUS-690442
...
415
Plug (Oil Pressure Switch Hole) HUS-794903
...
415A
Plug (Intake Manifold) HUS-690283
...
418
Plate-Carburetor HUS-795912
...
431
Elbow-Intake HUS-790816
...
445
Filter-Air Cleaner Cartridge HUS-499486S
...
447
Screw (Air Guide Cover) (Long) HUS-691003
...
447A
Screw (Air Guide Cover) (Short) HUS-697551
...
462
Washer (Starter Cable) HUS-691261
...
467
Knob-Air Cleaner HUS-691008
...
474
Alternator HUS-696458
...
501
Regulator HUS-691185
...
505
Nut (Governor Control Lever) HUS-691029
...
510
Drive-Starter HUS-696541
...
512
Hose-Oil Drain HUS-796530
...
513
Clutch-Drive HUS-692024
...
523
Dipstick HUS-691036
...
524
Seal-Dipstick Tube Included in Engine Gasket Set, Key. No. 358 HUS-691032
...
525
Tube-Dipstick HUS-691037
...
526
Screw (Regulator) HUS-697551
...
552
Bushing-Governor Crank HUS-690552
...
552A
Bushing-Governor Crank HUS-690553
...
562
Screw (Governor Control Lever) HUS-690311
...
573
Plate-Back HUS-790444
...
601
Hose-Clamp (Green) HUS-791850
...
601A
Hose-Clamp (Black) HUS-691038
...
615
Retainer-Governor Shaft HUS-698290
...
616
Crank-Governor HUS-691045
...
617
Seal-O Ring (Intake Manifold) (Red) Included in Engine Gasket Set, Key. No. 358; Included in Carburetor Overhaul Kit, Key, No. 121 HUS-697891
...
628
Screw (Fuel Pump Bracket) HUS-697551
...
633
Seal-Choke/Throttle Shaft (Choke Shaft) HUS-699813
...
635
Boot-Spark Plug HUS-66538S
...
654
Nut (Carburetor) HUS-690958
...
668
Spacer (Rotating Screen) HUS-691215
...
672
Gasket-Carburetor Plate HUS-690234
...
691
Seal-Governor Shaft Included in Engine Gasket Set, Key. No. 358 HUS-790574
...
697
Screw (Drive Cap) HUS-690372
...
703
Clip HUS-691010
...
718
Pin-Locating HUS-690959
...
742
Retainer-E Ring HUS-690328
...
750
Screw (Oil Pump Cover) HUS-796208
...
783
Gear-Pinion HUS-695708
...
788
Bracket-Fuel Pump HUS-793145
...
789
Harness-Wiring HUS-698330
...
798
Screw (Rocker Arm) HUS-697890
...
801
Cap-Drive HUS-691283
...
802
Cap-End HUS-691286
...
847
Dipstick/Tube Assembly HUS-499602
...
850
Sealant-Liquid (Used to Seal Breather Assembly and Rocker Cover) HUS-100106
...
851
Terminal-Spark Plug HUS-493880S
...
865
Cover-Air Guide (Cylinder #1) HUS-691012
...
865A
Cover-Air Guide (Cylinder #2) HUS-796541
...
865B
Cover-Air Guide (Cylinder #3) HUS-691015
...
868
Seal-Valve Included in Valve Gasket Set, Key No. 1095; Included in Engine Gasket Set, Key. No. 358 HUS-690968
...
877
Wire/Connector-Alternator HUS-790544
...
883
Gasket-Exhaust Included in Engine Gasket Set, Key. No. 358 HUS-690970
...
914
Screw (Rocker Cover) HUS-691127
...
918
Hose-Vacuum HUS-793147
...
943
Seal-O Ring (Oil Pump Cover) Included in Engine Gasket Set, Key. No. 358 HUS-796222
...
947
Solenoid-Fuel HUS-699728
...
965
Cover-Oil Pump HUS-796221
...
967
Filter-Pre Cleaner HUS-273638S
...
968
Cover-Air Cleaner HUS-791242
...
975
Bowl-Fuel HUS-499810
...
987
Seal-Throttle Shaft Included in Carburetor Overhaul Kit, Key, No. 121 HUS-691000
...
1005
Fan-Flywheel HUS-791236
...
1013
Nipple-Oil Filter HUS-690954
...
1017
Screen-Oil Pump HUS-796214
...
1022
Gasket-Rocker Cover (Liquid Gasket and Rocker Cover Gasket are Interchangeable) Included in Valve Gasket Set, Key No. 1095; Included in Engine Gasket Set, Key. No. 358 HUS-690971
...
1023
Cover-Rocker (Cylinder #1) HUS-793146
...
1023A
Cover-Rocker (Cylinder #2) HUS-499600
...
1024
Pump-Oil HUS-796220
...
1026
Rod-Push (Steel) HUS-690981
...
1026A
Rod-Push (Aluminum) HUS-690982
...
1027
Filter-Oil HUS-492932S
...
1029
Arm-Rocker HUS-690972
...
1051
Ring-Retaining HUS-691265
...
1054
Tie-Cable HUS-280275
...
1058
Operator’s Manual HUS-276245
...
1059
Kit-Screw/Washer HUS-698516
...
1070
Screw (Flywheel Fan) HUS-791680
...
1090
Retainer-Brush HUS-691293
...
1095
Gasket Set-Valve HUS-694013
...
1000
Pivot-Rocker Arm HUS-791959
...
1119
Screw (Alternator) HUS-691183
...
1124
Seal-O Ring (Fuel TransferTube) HUS-690988
...
1126
Screw (Fuel Transfer Tube) HUS-690991
...
1127
Screw (Float Bowl) HUS-690992
...
1128
Screw (Carburetor Nozzle) HUS-690990
...
1329
Replacement Engine HUS-44Q777- 0037
...
1330
Repair Manual HUS-273521
...
1342
Extension-Fuel Transfer Tube HUS-699731
...
1353
Seal-O Ring (Fuel Transfer Tube Extension) HUS-699725
