Husqvarna YT 1942 (96043002500) (2008-04) Ride Mower

Model: YT 1942 (96043002500) (2008-04)

Back To Assemblies

Save Part Not Listed?
product name

Chassis

...
...
3
LOGO.HUSQ.GT.LT.CROWN.H HUS-532430771
...
5
SUBASM.DASH.UPPER.W/BUMPER HUS-532438964
...
14
HOOD.HUSQVARNA.LT.ORANGE HUS-532441267
...
15
LENS.HUSQVARNA LT.LH HUS-532406664
...
18
ASM.GRILLE HUSQVARNA.LT.498 HUS-532439421
...
25
LENS.HUSQVARNA LT.RH HUS-532406663
...
34
PLATE.ENGINE.WELDED.CHASSIS HUS-580910801
...
36
BOLT.5/16-18UNCX3/4 W/SEMS.BLK HUS-532171877
...
37
FENDER.TLT.FS.W/CUPHLD.ORANGE HUS-532441266
...
52
Hardware HUS-596040501
...
68
Screws HUS-596030701
...
130
Screws HUS-596321701
...
137
BUMPER DASH HUS-532407590
...
138
HOLDER.CUP.LT.GREY HUS-532439747
...
150
DUCT.AIR. HUS-532407537
...
151
BRACKET PIVOT HUS-532407807
...
152
SERVICE KIT SHIELD SHIELD.BROW HUS-531169901
...
162
Screws HUS-596134101
...
175
CROSSMEMBER HUS-532199472
...
176
SCREW.#10-24X5/8.RN.QU HUS-532400776
...
177
BUSHING STEERING HUS-532195228
...
180
KITS.CHASSIS.WELD.SERVICE HUS-579841501
...
181
BUSHING.MNT.FEND.CRGO. HUS-532403025
...
182
DASH LOWER HUS-532198917
...
183
Screws HUS-595305701
...
189
BOLT.HEX.HD.WASHER.5/16-18X.75 HUS-532428867
...
191
INSERT REFLECTIVE HUS-532406665
...
194
GSPW Nuts HUS-596135701
...
195
PLUG.TEX.DASH.SVC.MINDER.GREY HUS-532439976
...
196
CONSOLE.ASM.DECKLFT.BL/RBT.TLT HUS-532414579
...
202
VENT SIDE HOOD HUS-532406671
...
203
VENT SIDE HOOD HUS-532406670
...
204
SUBASM.TOP.VENT.HUSQ.LT HUS-532441375
...
205
SKIRT.SIDE.HUSQVARNA.LT.RH.GRE HUS-532406668
...
206
SKIRT.SIDE.HUSQVARNA.LT.LEFT HUS-532441345
...
213
SCREW HEXAGON HEAD SCREW 5/16- HUS-596030501
...
214
CLIP.RETAINER.TINNER. HUS-532199145
...
217
ROD.PIVOT.HOOD HUS-532409167
...
218
X-PIECE.HOOD.STOP.NON/ HUS-532196395
...
228
STUD.W/"D"ANTI-ROTATION HUS-593824001
...
230
SHOULDER BOLT 5/16-18TT HUS-532170165
...
234
BUMPER.HOOD.TEX.HUSQVARNA HUS-532404742
...
235
Spacers HUS-596564201
...
236
NUT.CENTERLOCK.5/16- HUS-873930500
...
238
TRIM.HUSQ LT.668 HUS-532407881
...
239
IS ITO HUS-532404883
