Husqvarna Y18H44D (1994) Tractor

Model: Y18H44D (1994)

Back To Assemblies

Save Part Not Listed?
product name

18HP 44"/CHASSIS AND ENCLOSURES

...
...
1
SUB= 145501 HUS-140341
...
2
SUB= 145009 HUS-140356
...
3
SCREW HUS-17490612
...
6
SUB= 127543X011 HUS-127543
...
8
"CLIP,INSULATOR" HUS-126471X
...
9
DASHBOARD BLACK HUS-140398
...
10
SUB= 72110608 HUS-72140608
...
11
PANEL.DASH.LH HUS-136967
...
13
PANEL.DASH.RH HUS-136970
...
14
SCREW LT HUS-17490608
...
15
SCREW HUS-74180512
...
16
NUT HUS-73510500
...
17
SUB= 150301X505 HUS-132635X505
...
20
PLATE.SUPT.BATTER HUS-140181
...
24
BOLT HUS-74780616
...
25
WASHER HUS-19131312
...
26
NUT HUS-73800600
...
28
SUB= 131681X431 HUS-131681
...
29
LENS LT HUS-106395X
...
30
FENDER.PNT. HUS-140002X505
...
31
BRKT.ASM.FENDER HUS-137113
...
33
SUB= 145244X505 HUS-105465X505
...
34
SUB= 145243X505 HUS-105464X505
...
35
BOLT HUS-72110606
...
36
PAL NUT LT HUS-108067X
...
38
BRACKET ASM LH HUS-139886
...
39
BRACKET ASM RH HUS-139887
...
44
STRAP ASM FENDER HUS-140675
...
45
SUB= 147717 HUS-124392X417
...
47
NUT-PUSH YT HUS-105531X
...
48
SUB= 7605J HUS-123481X
...
50
SUPPORT ASS'Y HUS-124130X
...
51
NUT HUS-73800400
...
59
SUB= 9151R HUS-110436X
...
63
SPACER HUS-121236X
...
64
LOWER DASH HUS-104805X
...
65
BOLT HUS-74760532
...
66
PLATE SLKSCR YP HUS-140299X012
...
67
WASHER HUS-19111116
...
69
SUB= 155013 HUS-106784X
...
70
SUB= 155013 HUS-104618X
...
71
NUT HXKEP 1/4X20 HUS-73640400
...
72
STRAP.GRILLE.PNT. HUS-144916X505
...
73
SCREW CRT HUS-17580408
...
76
BOLT HUS-74780620
...
77
SCREW HUS-74191008
...
78
LOCKWASHER HUS-10071000
...
79
WELDNUT HUS-2029J
...
80
HOOD LATCH T HUS-109808X
...
81
SUB= 146525 HUS-123198X
...
82
SCREW HUS-74981020
...
83
SPACER LT HUS-7206J
...
84
WASHER HUS-19070818
...
85
NUT HUS-73731000
...
86
PANEL SIDE RH HUS-140679X505
...
87
SUB= 150302X505 HUS-140678X505
...
88
SCREW LT HUS-17211010
...
89
"""J"" FASTENER LT" HUS-104755X
...
90
WASHER PM HUS-19091216
...
91
SUB= 50675 HUS-73220400
...
92
LOCKWASHER HUS-10040400
...
96
NUT HUS-73800500
...
xx
PLUG-DASH T HUS-8022J
...
xx
COVER ACCESS HUS-121794X
