Husqvarna XC1122B (1991) Tractor

Model: XC1122B (1991)

Back To Assemblies

Save Part Not Listed?
product name

TRANSAXLE FOOTE - MODEL NUMBER 4360-7

...
...
1
Housing, Upper HUS-532120458
...
2
Screw, Tapping, Lg. 1/4-20 x .734 HUS-532002274
...
3
Ball, Detent HUS-532068003
...
4
Spring, Detent HUS-532105904
...
5
Screw, Set HUS-532105905
...
6
Assembly, Shifter HUS-532120460
...
7
O-Ring HUS-532120461
...
8
Washer, Plain .505 x .942 x .006 Use in combinations to maintain proper clearances. HUS-532120462
...
8
Washer, Plain .505 x .942 x .010 Use in combinations to maintain proper clearances. HUS-532120463
...
8
Washer, Plain .505 x .942 x .015 Use in combinations to maintain proper clearances. HUS-532120464
...
8
Washer, Plain .505 x .942 x .020 Use in combinations to maintain proper clearances. HUS-532120465
...
8
Washer, Plain .505 x .942 x .026 Use in combinations to maintain proper clearances. HUS-532120466
...
8
Washer, Plain .505 x .942 x .030 Use in combinations to maintain proper clearances. HUS-532083818
...
8
Washer, Plain .505 x .942 x .040 Use in combinations to maintain proper clearances. HUS-532120467
...
9
Ring, Retaining HUS-532002286
...
10
Ring, Retaining HUS-532002267
...
11
Washer, Plain .632 x 1.00 x .010 Use in combinations to maintain proper clearances. HUS-532003413
...
11
Washer, Plain .632 x 1.00 x .020 Use in combinations to maintain proper clearances. HUS-532002233
...
11
Washer, Plain .632 x 1.00 x .026 Use in combinations to maintain proper clearances. HUS-532002232
...
11
Washer, Plain .632 x 1.00 x .031 Use in combinations to maintain proper clearances. HUS-532002231
...
11
Washer, Plain .632 x 1.00 x .036 Use in combinations to maintain proper clearances. HUS-532002230
...
11
Washer, Plain .632 x 1.00 x .041 Use in combinations to maintain proper clearances. HUS-532002229
...
11
Key, Woodruff #9 Use in combinations to maintain proper clearances. HUS-532125096
...
11
Washer, Plain .632 x 1.00 x .050 Use in combinations to maintain proper clearances. HUS-532002227
...
11
Washer, Plain .632 x 1.00 x .060 Use in combinations to maintain proper clearances. HUS-532002226
...
11
Washer, Plain .632 x 1.00 x .082 Use in combinations to maintain proper clearances. HUS-532105906
...
12
O-Ring HUS-532006725
...
13
Washer, Plain .632 x 1.38 x .046 HUS-532120415
...
14
Key, Woodruff #9 HUS-532002257
...
15
Assembly, Kit, Input Shaft HUS-532110077
...
16
INPUT SHAFT HUS-532167148
...
17
Ring, Retaining HUS-532105909
...
18
Chain, 24 Pitches HUS-532105910
...
19
Bearing, Flange HUS-532105911
...
20
Gear, Spur, 14 Teeth HUS-532108976
...
21
Collar, Clutch HUS-532105913
...
22
Key, Clutch HUS-532120468
...
23
Key, Woodruff HUS-532002242
...
24
Shaft, Intermediate HUS-532120469
...
25
Key, Woodruff #61 HUS-532002244
...
26
Ring, Retaining HUS-532105916
...
27
Sprocket, 18 Teeth HUS-532120470
...
28
Spacer HUS-532110070
...
29
Gear, Spur, 37 Teeth HUS-532108977
...
30
Gear, Spur, 35 Teeth HUS-532109254
...
31
Gear, Spur, 30 Teeth HUS-532120405
...
32
Gear, Spur, 25 Teeth HUS-532108980
...
33
Gear, Spur, 22 Teeth HUS-532120406
...
34
Gear, Spur, 19 Teeth HUS-532108455
...
35
Washer, Plain .640 x 1.37 x .061 HUS-532105925
...
36
Washer, Plain .632 x 1.00 x .026 HUS-532002232
...
37
Spacer .630 x 1.00 x .169 HUS-532108978
...
38
Assembly, Gear, Combination 12 Teeth and 35 Teeth HUS-532110079
...
39
Shaft, Idler HUS-532120471
...
40
Spacer .635 x.875 x .755 HUS-532120472
...
41
Sprocket, 9 Teeth HUS-532105928
...
42
INPUT SHAFT HUS-532167148
...
43
Washer, Plain .758 x 1.12 x .010 Use in combinations to maintain proper clearances. HUS-532108983
...
43
Washer, Plain .758 x 1.12 x .015 Use in combinations to maintain proper clearances. HUS-532105930
...
43
Washer, Plain .758 x 1.12 x .020 Use in combinations to maintain proper clearances. HUS-532105931
...
43
Washer, Plain .758 x 1.12 x .025 Use in combinations to maintain proper clearances. HUS-532105932
...
43
Washer, Plain .758 x 1.12 x .020 Use in combinations to maintain proper clearances. HUS-532124916
...
43
Washer, Plain .758 x 1.12 x .025 Use in combinations to maintain proper clearances. HUS-532106097
...
43
Washer, Plain .758 x 1.12 x .031 Use in combinations to maintain proper clearances. HUS-532002264
...
43
Washer, Plain .758 x 1.12 x .035 Use in combinations to maintain proper clearances. HUS-532106098
...
43
Washer, Plain .758 x 1.12 x .040 Use in combinations to maintain proper clearances. HUS-532002265
...
43
Washer, Plain .758 x 1.12 x .045 Use in combinations to maintain proper clearances. HUS-532106586
...
43
Washer, Plain .758 x 1.12 x .050 Use in combinations to maintain proper clearances. HUS-532106587
...
43
Washer, Plain .758 x 1.12 x .055 Use in combinations to maintain proper clearances. HUS-532106588
...
43
Washer, Plain .758 x 1.12 x .062 Use in combinations to maintain proper clearances. HUS-532002263
...
44
Shaft, Drive HUS-532120473
...
45
Gear, Spur, 37 Teeth HUS-532108977
...
46
Gear, Spur, 15 Teeth HUS-532106151
...
47
Gear, Spur, 20 Teeth HUS-532120407
...
48
Gear, Spur, 25 Teeth HUS-532106589
...
49
Gear, Spur, 28 Teeth HUS-532120408
...
50
Gear, Spur, 31 Teeth HUS-532105937
...
51
Washer, Plain .632 x 1.00 x .060 HUS-532002226
...
52
Seal, Felt HUS-532002272
...
53
Washer, Plain .758 x 1.25 x .062 HUS-532002263
...
54
AXEL KIT, LH HUS-532154658
...
55
GEAR KIT HUS-532169651
...
56
Ring, Retaining HUS-532105941
...
57
Gear, Spur, 32 Teeth HUS-532110071
...
58
Shaft, Cross HUS-532120952
...
59
GEAR KIT HUS-532169651
...
60
Axle, R.H. HUS-532120475
...
61
Housing, Lower HUS-532120476
...
62
Puck, Friction HUS-532120961
...
63
Disc, Brake HUS-532007294
...
64
Spacer HUS-532108989
...
65
JAW BRAKE HUS-532164670
...
66
Pin, Dowel HUS-532120954
...
67
Screw, Tapping, Lg. 5/16-18 x 2.25 HUS-532120955
...
68
Lever, Actuating HUS-532108992
...
69
Washer, Plain .321 x 1.00 x .055 HUS-532108996
...
70
Bracket, Anti-Rotation HUS-532120956
...
71
NUT HUS-873610500
...
72
Screw, Tapping, Lg. 5/16-18 x 1.44 HUS-532106596
...
73
Washer, Plain .343 x .81 x .059 HUS-532120993
...
74
Puck, Friction HUS-532120951
...
75
Shell Durina-O Grease (20 oz.) HUS-532126976
