Husqvarna ST 230P Snow Blower

Model: ST 230P

Back To Assemblies

Save Part Not Listed?
product name

"CHASSIS, ENGINE & PULLEYS"

...
...
39
PUSH CLIP HUS-532145006
...
20
HEX.WASHER.HEAD 1/4-20 X .65 HUS-585517801
...
13
WASHER 11/32 X 11/16 X 14 GA T For 96191009005, 96193010106 HUS-596204101
...
13
WASHER 11/32 X 11/16 X 14 GA T For all EXCEPT 96191009005, 96193010106 HUS-596204101
...
7
HIGH CRANK IMPELLER BELT HUS-501818202
...
11
BOLT HEXAGON BOLT 5/16-18 X 7/ HUS-596322201
...
2
SPRING RETURN, IDLER ARM, IMPE HUS-587031201
...
41
BRACKET.FRAME.SUP.LARGEENG.BLA HUS-585546002
...
26
BRACKET.BELT.KEEPER.LOWER.BLAC HUS-581632002
...
37
COVER BELT, HIGH HUS-585771101
...
18
SCREW HEXAGON HEAD FLANGE 3/8- HUS-595517901
...
9
BOLT.ENGINE.PULLEY HUS-582388401
...
4
BOLT 5/16-24X2.25 HEX HEAD SHO HUS-581413801
...
22
PULLEYS HUS-536862701
...
35
SCREW HEXAGON HEAD WITH COLLAR HUS-593337201
...
36
SCREW.HEX HEAD W/COLLAR 1/4-20 HUS-582906901
...
14
BOLT, HEX 5/16-18X1-3/4 HUS-874760528
...
32
SCREW.HEX HEAD W/COLLAR 1/4-20 HUS-582906901
...
19
NUT HEXAGON FLANGE 5/16-18 ST HUS-594944401
...
xx
ENGINE RATO 301CC (CARB) For 97046810100, (See Husqvarna Engine IPL for service parts) HUS-598609803
...
23
GUIDE.LOWER.AUGER.BELT.479 HUS-587587202
...
6
BELT KEEPER BRACKET HUS-588492802
...
xx
ENGINE.LCT.291CC.ST FORCE.SNO For all EXCEPT, 96193010105, 96193010106 (See LCT Engine IPL for serice parts) HUS-580426108
...
xx
ENGINE.LCT.291CC.SNO.16 For 96193010105, (See LCT Engine IPL for service parts) HUS-580426107
...
17
PULLEY.ASM.IMPELLER/DRIVE HUS-587893703
...
16
PULLEY.IDLER.FLNGLESS.W/SPACER HUS-586880202
...
24
Screws HUS-596031601
...
38
For 96191009005, BOLT HEX WSH THDRL 1/4-20 X 1 HUS-000000000
...
3
SPRING RETURN IDLER ARM HUS-580753001
...
40
For 96191009005 HUS-000000000
...
28
FRAME MS 668 HUS-589264705
...
15
PULLEYIDLER.2.0.W/SPACER.CZ HUS-581141402
...
25
NEEDS DESCRIPTION HUS-581592503
...
10
SCREW 5/16-24 X .75 GR5 HUS-874610512
...
38
For all EXCEPT 96191009005 HUS-000000000
...
5
RP_BELT.DRIVE.HI-CRANK HUS-585829901
...
31
BRACKET.SHIFTER.BZP HUS-501060403
...
40
For 96191009005, PALNUT 1/4 IN HUS-000000000
...
1
BUSHING.BRAKE.ARM HUS-587343701
...
27
ARM DRIVE IDLER CLEAR ZINC PLA HUS-593192502
...
33
WIREFORM.SUPPORT.CABLE HUS-588954501
...
34
BOLT.HEX.HD.WASHER.5/16-18X.75 HUS-532428867
...
xx
ENGINE LCT 208CC 6.3HP DSST OP For 96193010106, (See LCT Engine IPL for service parts) HUS-590218603
...
12
WASHER SPRING LOCK WASHER WITH HUS-596238801
...
30
COVER COVER.FRAME MS668 ORANGE HUS-580839505
...
8
ARM.IDLER.AUTO-PH.676 HUS-580831106
...
29
BOLT 3/8-16X1-1/8 HUS-532150406
...
21
BRACKET NUT BLACK ZINC PLATE HUS-590044602
