Husqvarna RZ 4216 - 966612401 (2012-02) Zero Turn Mower

Model: RZ 4216 - 966612401 (2012-02)

Back To Assemblies

Save Part Not Listed?
product name

BRAKE / REAR MOWER LIFT

...
...
22
Washers HUS-596581701
...
27
Screws HUS-596584001
...
19
Pins HUS-596273101
...
13
BRAKE SWIVEL HUS-539112308
...
6
LINKAGE, EZT BRAKE LT LH HUS-525583701
...
25
GSPW Nuts HUS-596240901
...
24
Nuts HUS-596583702
...
15
SPRING HUS-539101224
...
23
WASHER, .825 X 1.087, WAVE HUS-539133007
...
12
PLASTIC BUSHING HUS-539109368
...
10
GRIP.HANDLE.LIFT.PVC.BLACK HUS-532411555
...
14
SWIVEL HUS-539118179
...
4
LINKAGE, BRAKE, UPPER HUS-525735701
...
21
WASHER 11/32 X 11/16 X 14 GA T HUS-596204101
...
16
L ROD 3-1/8" HUS-539115247
...
2
SHAFT, LIFT WLDMT, BLACK HUS-574356802
...
9
ROD, BRAKE HUS-574356601
...
26
RHSNB 3/8-16 X 1-1/4 HUS-539100413
...
20
GSPW Washers HUS-596433701
...
3
BELLCRANK, BRAKE HUS-525580201
...
7
BRAKE ARM PIVOT HUS-539120220
...
1
ARM, LIFT HANDLE, BLK HUS-525580402
...
18
Pins HUS-596580601
...
17
ROLL PIN 3/16 X 1-1/4 ZD HUS-539101082
...
5
LINKAGE, EZT BRAKE RT RH HUS-525583601
...
11
GRIP BRAKE HANDLE HUS-539120921
...
8
HANDLE, BRAKE, BLK HUS-525485602
