Husqvarna PR7R21A (2004-07) Walk-Behind Mower

Model: PR7R21A (2004-07)

Back To Assemblies

Save Part Not Listed?
product name

Frame

...
...
1
Drive Control Assembly HUS-189181
...
2
Control Bar, Drive HUS-188975
...
3
Nut, Hex HUS-751152
...
4
Screw HUS-185681
...
5
Cover, Drive HUS-161537X428
...
6
Screw, Threaded, Rolled #10-25 x .50 HUS-750634
...
7
V-Belt HUS-182212
...
8
Nut, Flangelock, Zinc Plated 3/8-16 HUS-132010
...
9
Pulley, Drive HUS-184749
...
10
Pinion, Gear HUS-175103
...
11
Screw HUS-187653
...
12
Retainer, Drive, RH HUS-175102
...
13
Gear Case Assembly, Complete HUS-187213
...
14
Pin, Spring, Thrust HUS-145354
...
15
Washer, Hardened HUS-57079
...
16
Rod, Connecting HUS-161584
...
17
Spring, Extension HUS-161602
...
18
Spring, Selector HUS-160477X004
...
19
Knob, Selector Spring HUS-189808X421
...
20
E-Ring 7/8 HUS-12000022
...
21
Bearing, Support HUS-163365
...
22
Bearing, Ball HUS-169911
...
23
Retainer, Drive Assembly HUS-161118X004
...
24
Screw, Tapping, Hex Head 1/4-20 x .75 HUS-57808
...
25
Pawl HUS-175098
...
26
Spring, Torsion HUS-188291
...
27
Washer, Shim (as required) HUS-52160
...
28
E-Ring 7/16 HUS-12000058
...
29
Cover, Dust, Wheel HUS-180504
...
30
Disc, Drive HUS-175104
...
31
Nut, Flangelock HUS-145212
...
32
Wheel, Rear, Self-Propelled 9 x 2 HUS-180764
...
33
Nut, Flangelock 3/8-16 HUS-83923
...
34
Hubcap, Mag, Platinum HUS-77400
...
35
Shaft Assembly, Rear HUS-160785 X004
...
36
Shaft Assembly, Front HUS-160786X004
...
37
Retainer, Front Shaft HUS-161463
...
38
Screw #12 x 5/8 HUS-163409
...
39
Clip, Retainer HUS-700279
...
40
Wheel, Front 8 x 2 HUS-172297
...
41
Seal, Friction HUS-175101
...
42
Pinion / Pawl Assembly, RH HUS-188293
...
43
Washer HUS-19572216
...
44
Pinion / Pawl Assembly, LH HUS-188292
...
45
Washer HUS-67725
...
46
Retainer, Drive, LH HUS-175105
...
50
Case, Lower Use Dow Corning #709 to reseal Gear Case Halves. HUS-187530
...
51
Case, Upper Use Dow Corning #709 to reseal Gear Case Halves. HUS-187531
...
52
Gear, 24 Teeth HUS-187532
...
53
Shaft, Input HUS-187533
...
54
Wire, Formed HUS-183505
...
55
Bearing, Ball HUS-183506
...
56
Seal, Output Shaft HUS-183508
...
57
Washer HUS-183509
...
58
Bushing HUS-183511
...
59
Shaft, Output HUS-187534
...
60
Screw HUS-183513
...
61
Seal, Input Shaft HUS-183514
