Husqvarna P325 (2010-04) Blower

Model: P325 (2010-04)

Back To Assemblies

Save Part Not Listed?
product name

HOUSING

...
...
1
SCREW HUS-530015814
...
2
ASSY COVER ENGINE HUS-545135806
...
3
SCREW HUS-530015880
...
4
SHIELD BAFFLE HUS-545134001
...
5
BAFFLE HUS-545099101
...
6
SCREW SEMS TOOTHED WASHER HUS-530016391
...
7
KIT STARTER PULLEY HUS-545081852
...
8
KIT STARTER SPRING HUS-545008011
...
9
TUBE STARTER ROPE HUS-545107101
...
10
HANDLE STARTER BLK HUS-530054834
...
11
KIT ROPE HUS-545081833
...
12
KIT SWITCH (Incl 13) HUS-545081830
...
13
PROTECTOR, SWITCH HUS-545128201
...
14
HUB HUS-545099001
...
15
NUT HUS-530626605
...
16
TRIGGER THROTTLE RED HUS-545113803
...
17
Assy - Scroll LH (Incl 19 20) HUS-545134103
...
18
SCREW HUS-530015814
...
19
DOOR VAC BLACK HUS-545100801
...
20
SPRING VAC DOOR HUS-545115601
...
21
HUS-545003502
...
22
SCREW #10 PLASTITE 1.362 HUS-530016406
...
23
LOCK WASHER HUS-530092322
...
24
WASHER, IMPELLER HUS-545109901
...
25
ASSY IMPELLAR HUB HUS-545113601
...
26
SPACER FLYWHEEL HUS-545113701
...
27
NUT HUS-530015197
...
28
SCREW HUS-530016386
...
29
(Incl 14) HUS-545100903
...
30
HANDLE VAC BLACK HUS-545101201
...
31
Assy - Fuel Tank (Incl 32 33 34 35) HUS-545100401
...
32
FUEL PICK-UP ASSY HUS-530095646
...
33
KIT-LINE HUS-530069247
...
34
LINE KIT HUS-530069216
...
35
ASSY FUEL CAP W/RETAINER HUS-530057973
...
36
SCREW FUEL TANK RETAINER HUS-530016445
