Husqvarna AYP9167A59 (1995) Tractor

Model: AYP9167A59 (1995)

Back To Assemblies

Save Part Not Listed?
product name

ENGINE/B&S

...
...
1
CYLINDER ASSEMBLY HUS-807511
...
2
BEARING, CYLINDER HUS-805107
...
3
SEAL, OIL HUS-805101
...
5.1
HEAD, CYLINDER #1 HUS-807508
...
5.2
HEAD, CYLINDER #2 HUS-807510
...
6
WASHER, CYLINDER HEAD HUS-805193
...
7
GASKET, CYLINDER HEAD HUS-805111
...
8
BREATHER ASSEMBLY HUS-807795
...
9
GASKET, BREATHER HUS-805379
...
10
SCREW HUS-805751
...
11
TUBE, BREATHER HUS-805362
...
12
GASKET, CRANKCASE COVER HUS-805112
...
13
SCREW, CYLINDER HEAD HUS-805097
...
15
PLUG, OIL DRAIN HUS-805048
...
16
CRANKSHAFT HUS-807586
...
xx
KEY, TIMING GEAR HUS-94196
...
xx
WASHERS, THRUST HUS-807625
...
18
COVER ASSEMBLY, CRANKCASE HUS-807638
...
20
SEAL, OIL HUS-805049
...
22
SCREW, CRANKCASE COVER HUS-805017
...
23
FLYWHEEL MAGNETO HUS-807531
...
24
KEY, FLYWHEEL HUS-805016
...
25
PISTON ASSEMBLY, STANDARD HUS-807619
...
xx
PISTON ASSEMBLY .010" OVERSIZE HUS-807807
...
xx
PISTON ASSEMBLY .020" OVERSIZE HUS-807809
...
xx
PISTON ASSEMBLY .030" OVERSIZE HUS-807811
...
26
RING SET, PISTON, STANDARD HUS-807620
...
xx
RING SET, PISTON .010" OVERSIZE HUS-807808
...
xx
RING SET, PISTON .020" OVERSIZE HUS-807810
...
xx
RING SET, PISTON .030" OVERSIZE HUS-807812
...
27
LOCK, PISTON PIN HUS-805099
...
28
PIN ASSEMBLY, PISTON, STANDARD HUS-807621
...
29
ROD ASSEMBLY, CONNECTING HUS-807622
...
32
SCREW, CONNECTING ROD HUS-805395
...
33
VALVE, EXHAUST HUS-805089
...
34
VALVE, INTAKE HUS-805090
...
35
SPRING, VALVE HUS-805078
...
40
RETAINER, VALVE SPRING HUS-805092
...
42
RETAINER, VALVE HUS-805161
...
45
TAPPET, VALVE HUS-805354
...
46
GEAR, CAM HUS-807542
...
50
MANIFOLD, INTAKE HUS-805409
...
51
GASKET, CARBURETOR MOUNTING HUS-805149
...
52
GASKET, INTAKE MANIFOLD HUS-805023
...
53
SCREW, SEMS HUS-805360
...
54
SCREW, SEMS HUS-805006
...
75
WASHER, SPRING HUS-805007
...
78
SCREW, SEMS HUS-805447
...
84
PLUG, PIPE HUS-305059
...
87
SEAL, GOVERNOR SHAFT HUS-805054
...
94
NOZZLE, CARBURETOR HUS-805777
...
95
SCREW, VALVE MOUNTING HUS-805561
...
98
SCREW, THROTTLE ADJUSTING HUS-807705
...
104
PIN, FLOAT HINGE HUS-805586
...
105
VALVE, FUEL INLET HUS-807706
...
108
VALVE, CHOKE HUS-805562
...
116
O-RING, OIL PUMP HUS-805058
...
116A
O-RING, CRANKCASE COVER HUS-805198
...
118
VALVE ASSEMBLY, CARBURETOR IDLE HUS-807707
...
121
CARBURETOR OVERHAUL KIT HUS-807962
...
122
SPACER, CARBURETOR HUS-805329
...
125
CARBURETOR, ASSEMBLY HUS-807961
...
127
PLUG, WELCH HUS-805570
...
127A
PLUG, WELCH HUS-805571
...
130
VALVE, THROTTLE HUS-805572
...
131
SHAFT, THROTTLE HUS-807709
...
133
FLOAT ASSEMBLY, CARBURETOR HUS-807710
...
141
SHAFT, CHOKE HUS-807711
...
147
NOZZLE HUS-807960
...
156
STUD, ROCKER ARM HUS-805343
...
161
BASE ASSEMBLY, AIR CLEANER HUS-807857
...
166A
STUD, OIL FILTER ADAPTER HUS-805073
...
167
WASHER, VALVE COVER HUS-805420
...
171
NUT, NYLOCK HUS-805019
...
187
HOSE (CUT TO SUIT) HUS-393815
...
xx
PIPE, FUEL HUS-296004
...
188
SCREW, STARTER MOUNTING HUS-805247
...
189
LOCK WASHER HUS-805449
...
192
SCREW, VALVE ADJUSTMENT HUS-807623
...
201
LINK, GOVERNOR HUS-805480
...
209
SPRING, GOVERNOR HUS-805462
...
209A
SPRING, GOVERNED IDLE HUS-805453
...
216
LINK, CHOKE HUS-805439
...
222
BRACKET, GOVERNOR CONTROL HUS-807610
...
227
LEVER ASSEMBLY, GOVERNOR HUS-807528
...
232
SPRING, GOVERNOR LINK HUS-805465
...
240
FILTER, FUEL HUS-394358
...
243
SCREEN, OIL HUS-805312
...
254
DRAIN, CARBURETOR BOWL HUS-807713
...
265
CLAMP HUS-221535
...
271
BRACKET, CHOKE CONTROL HUS-807609
...
277
WASHER HUS-805018
...
304
HOUSING, BLOWER HUS-807899
...
305
SCREW, SEMS HUS-805406
...
307
SCREW, SEMS HUS-805025
...
308.1
COVER, AIR GUIDE, CYLINDER #1 HUS-807868
...
308.2
COVER, AIR GUIDE, CYLINDER #2 HUS-807869
...
309
MOTOR, STARTING HUS-399169
...
310
BOLT HUS-94169
...
311
SCREEN ROTATING HUS-490311
...
324
SCREEN, ROTATING HUS-280829
...
332
NUT, HEX HUS-805021
...
333
ARMATURE, MAGNETO HUS-492341
...
334
SCREW, MOUNTING HUS-805407
...
337
PLUG, SPARK HUS-491055
...
353
WASHERLOCK HUS-92791
...
354
NUT, HEX HUS-90576
...
354A
NUT, HEX WASHER HEAD HUS-810078
...
356
WIRE ASSEMBLY, GROUND HUS-493792
...
358
GASKET SET HUS-807640
...
363
PULLER, FLYWHEEL HUS-19203
...
387
PUMP, FUEL HUS-491922
...
423
SCREW, SEMS HUS-805260
...
445
CARTRIDGE, AIR CLEANER HUS-394018
...
467
KNOB, AIR CLEANER HUS-491875
...
474
STATOR, ALTERNATOR HUS-393295
...
501
REGULATOR, ALTERNATOR HUS-394890
...
510
STARTER DRIVE GROUP HUS-490421
...
513
CLUTCH ASSEMBLY HUS-398003
...
520
TERMINAL, SPADE HUS-93722
...
523
DIPSTICK HUS-807516
...
524
SEAL, FILLER TUBE HUS-805011
...
525
TUBE, OIL FILLER HUS-807611
...
526
SCREW, REGULATOR MOUNTING HUS-805448
...
527
CLAMP, FUEL PUMP HUS-223167
...
535
ELEMENT, AIR CLEANER HUS-271271
...
537
GASKET, AIR CLEANER HUS-805655
...
544
ARMATURE ASSEMBLY HUS-490309
...
552
BUSHING, GOVERNOR SHAFT HUS-805412
...
552A
BUSHING, GOVERNOR SHAFT HUS-805413
...
562
BOLT HUS-805381
...
572
BAFFLE, BREATHER HUS-805197
...
573
BACK PLATE ASSEMBLY, BLACK HUS-307663
...
592
NUT, HEX HUS-805383
...
601
CLAMP, HOSE, GREEN HUS-93053
...
613
SCREW, SEMS HUS-805158
...
614
PIN, COTTER HUS-805417
...
615
RETAINER, CHOKE SHAFT HUS-805578
...
615A
RETAINER, THROTTLE SHAFT HUS-805577
...
616
FORK, GOVERNOR HUS-807596
...
634
WASHER, GOVERNOR SHAFT HUS-805416
...
634A
WASHER, THROTTLE HUS-805576
...
634B
COLLAR, THROTTLE HUS-805574
...
634C
COLLAR, CHOKE HUS-805580
...
635
ELBOW, SPARK PLUG HUS-805529
...
642
COVER ASSEMBLY, AIR CLEANER HUS-807862
...
643
PLATE, AIR FILTER HUS-805631
...
657
SCREW, SEMS HUS-805009
...
668
SPACER, ROTATING SCREEN HUS-805402
...
718
DOWEL, CRANKCASE HUS-805103
...
718A
DOWEL, CYLINDER HEAD HUS-805102
...
722
SEAL, BREATHER SCREW HUS-805483
...
726
GEAR, FLYWHEEL RING HUS-807805
...
727
SHIELD, STARTER HUS-805505
...
729
GROMMET, IGNITION CABLE HUS-805641
...
741
GEAR, TIMING HUS-805675
...
783
GEAR, STARTER HUS-280104
...
788
BRACKET, FUEL PUMP HUS-807685
...
801
CAP, DRIVE HUS-394856
...
802
CAP ASSEMBLY, COMMUTATOR END HUS-490310
...
803
HOUSING ASSEMBLY HUS-398892
...
819
SCREW, SEMS HUS-805057
...
823
SCREW, MOUNTING HUS-805317
...
842
O-RING HUS-805012
...
851
TERMINAL, IGNITION CABLE HUS-221798
...
862
BRACKET, AIR CLEANER HUS-807859
...
864
LINER, EXHAUST PORT HUS-805083
...
866
VALLEY, COVER, AIR GUIDE HUS-805738
...
868
SEAL, VALVE GUIDE HUS-805094
...
869
SEAT, INTAKE VALVE HUS-805085
...
870
SEAT, EXHAUST VALVE HUS-805086
...
871
GUIDE, VALVE HUS-805084
...
876
PINION SPRING KIT HUS-490467
...
879
COVER, CARBURETOR HUS-805636
...
883
GASKET, EXHAUST MANIFOLD HUS-805024
...
896
ROLL PIN HUS-94288
...
947
SOLENOID HUS-807744
...
955
PLUG AND SEAL, CARBURETOR HUS-807714
...
975
BOWL ASSEMBLY, FLOAT HUS-807715
...
977
CARBURETOR GASKET SET HUS-807716
...
978
GASKET, OIL FILTER ADAPTOR HUS-805250
...
982
SCREW, SEMS HUS-805030
...
985
INSULATOR ASSEMBLY HUS-398525
...
987
SEAL, THROTTLE SHAFT HUS-805575
...
1003
BRUSH SPRING SET HUS-490316
...
1004
TUBE, AIR INLET HUS-805632
...
1013
SEAL, CHOKE SHAFT HUS-805581
...
1014
DEFLECTOR, BREATHER, A.C. HUS-807797
...
1022
NUT, HEX HUS-805028
...
1023
COVER, VALVE HUS-805100
...
xx
COVER, VALVE HUS-807665
...
1024
OIL PUMP ASSEMBLY HUS-807546
...
1025
SLIDER, GOVERNOR HUS-805313
...
1026
ROD, PUSH, INTAKE HUS-805352
...
xx
ROD, PUSH, EXHAUST HUS-805617
...
1027
FILTER, OIL HUS-492932
...
1028
ADAPTER, OIL FILTER HUS-805292
...
1029
ARM, ROCKER HUS-807557
...
1030
SHAFT, ROCKER ARM HUS-805342
...
1031
SUPPORT, ROCKER ARM HUS-805341
...
1033
OVERHAUL KIT, VALVE HUS-807668
...
1036
BREATHER GASKET SET HUS-807688
...
1037
BALL, CHOKE LOCATOR HUS-807717
