Husqvarna 262 (2008-03) Chain Saw

Model: 262 (2008-03)

Back To Assemblies

Save Part Not Listed?
product name

Starter

...
...
1
Kit-Trigger & Lockout (Includes Pin) HUS-530071832
...
2
Lever-Switch HUS-530038227
...
3
Spring-Switch HUS-530016149
...
4
Screw HUS-530015775
...
5
Kit-Fuel Line (Large) HUS-530069216
...
6
Fitting - Fuel line HUS-530023877
...
7
FUEL CAP ASSY W/RET HUS-577858501
...
8
Clip - "U" HUS-530055322
...
9
Shield - Heat HUS-530055183
...
10
Lever-Choke HUS-530047989
...
11
Grommet-Choke lever HUS-530049005
...
12
Wire-Throttle HUS-530037809
...
13
Nut-Speed HUS-530015922
...
14
Assy.-Clutch HUS-530014949
...
15
Washer-Clutch HUS-530015611
...
16
Assy-Drum W/brg. HUS-530047061
...
17
Washer - Thrust HUS-530015907
...
18
Assy-Chassis ( Incl. # 1,5,6,7,13,30,31,32) HUS-530058908
...
19
Assy-Flywheel HUS-530039187
...
20
Washer-Flywheel HUS-530015127
...
21
Nut-Flywheel HUS-530016134
...
22
Screw HUS-530015920
...
23
Housing-Fan HUS-530049335
...
24
Screw HUS-530015892
...
25
Handle-Starter HUS-530056402
...
26
Kit-Rope HUS-530069232
...
27
SPRING STARTER HUS-545008015
...
28
STARTER PULLEY HUS-545034301
...
29
Screw HUS-530016080
...
30
Kit-Oil Check Valve HUS-530071666
...
31
Assy-Oil Cap HUS-530057236
...
32
Bolt - Bar HUS-530016133
...
33
Chain Catcher HUS-530029850
...
34
Screw HUS-530015814
...
35
Plate-Bar Mounting HUS-530038238
...
36
Assy.-Chain Brake HUS-545139915
...
37
Nut-Bar Mounting HUS-530015917
...
38
Bar- 18" HUS-530044835
...
39
Chain- 18" HUS-952051338
...
40
Screw HUS-530016132
...
41
Screw HUS-530015814
...
42
Handle-Front HUS-530059173
...
43
Screw HUS-530015940
...
44
Kit-Oil Pump (Incl 45,46,48) HUS-530071259
...
45
Gear-Worm Spring HUS-530037820
...
46
Elbow-Oil Pickup HUS-530049477
...
47
SCREW 6-19X.437 HUS-545227101
...
48
Block-Seal HUS-530019206
...
49
Assy-Oil-Pickup (Incl. 50, 51 ) HUS-530047663
...
50
Pickup-Oiler HUS-530038373
...
51
Filter-Oil HUS-530056533
