Husqvarna 130 L Trimmer/Edger

Model: 130 L

Back To Assemblies

Save Part Not Listed?
product name

CYLINDER

...
...
11
SCREW M4 X .70 TT 16MM HUS-530016456
...
24
SEAL CYLINDER HUS-545083301
...
27
SPARK PLUG Champion RCJ8Y HUS-530030218
...
8
WASHER CLUTCH UPPER HUS-525613001
...
29
ASSY MODULE LEAD WIRE HUS-530039227
...
28
SPRING CLUTCH HUS-587037001
...
23
WRIST PIN RET. HUS-530015162
...
25
PISTON HUS-529469901
...
14
FLYWHEEL HUS-510088202
...
17
CRANKSHAFT SEAL HUS-545004301
...
12
IGNITION MODULE TRIMMER FL28C HUS-599503502
...
22
RING PISTON HUS-575227901
...
3
GASKET HUS-529437401
...
2
BOLT MUFFLER HUS-530058982
...
26
PISTON PIN HUS-530032159
...
7
SCREW CLUTCH HUS-525615401
...
19
CRANKSHAFT HUS-585415405
...
18
BEARING RADIAL BALL (6201) HUS-545013401
...
4
KIT SPARK ARRESTOR SCREEN SPARK ARRESTOR HUS-545030501
...
10
WASHER CLUTCH LOWER HUS-525612901
...
6
SCREW 6-19X.437 HUS-545227101
...
13
FLANGE NUT HUS-731711651
...
21
KIT PISTON & CYLINDER HUS-545008082
...
15
CRANKCASE CAST 128 HUS-577929502
...
9
CLUTCH ASSY HUS-575762203
...
20
STARTER PAWL BRIDGE HUS-503873305
...
1
MUFFLER KIT HUS-531127912
...
16
SCREW-M5-0.8 X 25MM(TAP) HUS-530015897
