product name

Hoover 404 Swingette Vacuum

Model: 404

Save
 Part Not Listed?Part Not Listed?
product name

Hoover 404

...
...
x
Housing Assembly - R.H. - Jm HOO-42222028
...
x
Diffuser Door 162059DR
...
x
Diffuser Door 162059JX
...
xx
Housing Assembly - L.H. 37223057
...
1
Bag Door Assembly HOO-42227039
...
2
Bag Assembly Comp. HOO-43662023
...
3
Housing Assembly - R.H. 162064LL
...
4
Hinge Pin (2) HOO-162062AY
...
5
Nameplate 162483
...
6
Diffuser HOO-34366001
...
7
Diffuser Door 162059AG
...
8
Solderless Connector (2) HOO-48969
...
9
Cord Protector 36215030
...
10
Housing Muffler (2) 162066
...
11
Lead Wire Assembly - Black 12062
...
12
Lead Wire Assembly - Yellow 162075
...
13
Lead Wire Assembly - White 162074
...
14
Motor Brush Holder (2) HOO-12031
...
15
Switch 12971
...
16
Motor Brush Holder (2) 12029
...
17
Secondary Filter HOO-162083JM
...
18
Pressure Pad (3) 163434
...
19
Field Lamination Bold (2) 12022
...
20
Washer (2) HOO-21312701
...
21
Screw - Self Tapping (2) 21447028
...
22
Motor Brush Retainer (2) 12033
...
23
Motor Brush Housing Assembly HOO-12059
...
24
Compression Spring (2) 12854
...
25
Pin (3) HOO-12007
...
26
Nut - Special (2) 21651037
...
27
Attach Cord Assembly HOO-46363271
...
28
Washer (3) 21312700
...
29
Fan Assembly HOO-43566003
...
30
Fan Nut HOO-12000
...
32
Motor End Cap Assembly 12038
...
33
Motor Mount - R.H. HOO-12089
...
34
Interstage Housing HOO-18656
...
35
Fan Spacer 170055
...
36
Fan Spacer 12003
...
37
Armaure Assembly Comp. HOO-167673
...
38
Motor Casing 12050
...
39
Field Assembly Comp. 167677
...
40
Spacer 12013
...
41
Fan HOO-43566005
...
42
Nut 12028
...
43
Outerstage Housing Assembly 163426
...
44
Retaining Ring 163546
...
45
Motor Seal Mount 161957
...
46
Housing Assembly - L.H. 162065LL
...
47
Screw - Self Tapping (2) HOO-21447043
...
48
Screw - Self Tapping (4) HOO-21479573
...
49
Tool Holder 162060AW

Hoover 404

...
...
xx
Strain Relief Bushing (Used On Item 27) 27482227
...
xx
Terminal (Used On Item 13) HOO-160356
...
xx
Terminal (Used On Item 13) 161350
...
xx
Terminal (Used On Item 11 And 12) 160532

Hoover 404

...
...
xx
Carton - Portapower Without Dolly 58152062
...
xx
Carton 58172001

Hoover 404

...
...
xx
Retaining Ring HOO-160017
...
xx
Wheel Cover 169242
...
xx
Wheel (Includes Tire) 43247006
...
xx
Dolly Comp. 43248010

Hoover 404

...
...
x
Rivet (2) 12763AW
...
xx
Nozzle And Lock Assembly 43414089
...
xx
Cleaning Tool Bag 58544004
...
xx
Shag Rake 170110
...
xx
Furniture Brush 161852JM
...
xx
Rug And Floor Nozzle Assembly 633217A
...
xx
Furniture Brush - Ag 43414016
...
1
Gasket 12845JM
...
2
Tube Latch HOO-12846AG
...
3
Rivet (3) 12772
...
4
Rivet (3) 12783
...
6
Extension Tube Assembly - Inner HOO-12598
...
7
Extension Tube Assembly - Comp. 43458001
...
8
Reinforcement Plate 12824
...
9
Rivet 12600
...
10
Washer HOO-21312704
...
11
Gasket - Inner 12844JM
...
12
Extension Tube Guide HOO-12589
...
13
Extension Tube Assembly - Outer HOO-12597
...
14
Tube Latch - Outer 36152018
...
16
Crevice Tool HOO-38617017
...
22
Hose Assembly Comp. 43434223
...
23
Hose Connector 12593JM
...
24
Hose Connector Collar 12615BZ
...
25
Hose Sleeve (2) HOO-32156010
...
26
Hose Complete 43434213
...
28
Hose Grip Assembly Aap - S/C HOO-43466044
...
32
Hose Grip Collar HOO-12704BZ
...
33
Hose Grip Assembly Aap - S/C HOO-43466044
...
34
Suction Regulator Support 13257BZ
...
35
Machine Screw 13275
...
36
Suction Regulator 13142AG
...
38
Brush (Use W/L 61851 Jm) 13263BZ
...
39
Dusting Brush (One Piece) HOO-43414064
...
40
Furniture Nozzle Assembly HOO-43414057
...
41
Brush Retainer Clip HOO-166646
...
42
Screw - Self Tapping (2) HOO-166648AW
...
43
Nozzle Tube Clamp 166650AY
...
44
Brush Back Assembly 166656
...
45
Spring (2) HOO-166649FW
...
46
Nozzle And Lock Assembly 166763DM
...
47
Nozzle Tube Comp. 166652JM
...
48
Gasket (Felt) HOO-166651
...
49
Rug And Floor Nozzle Assembly OM114169
...
54
Extension Tube - Poly - Ag HOO-3863801P
...
55
Extension Tube HOO-43453027
...
...
...
...
...
