product name

3822B Eureka Rally Canister

Model: 3822B
Save
 Don't See Your Part Listed?
product name

Eureka 3822B

...
...
1
Wand - Straight 14070-3
...
2
Elbow 38401-1
...
3
Insert - Ringlock Brush 33787
...
4
Spring - Carpet Nozzle 42797
...
5
Brush 46186
...
6
Upholstery Nozzle Assembly 53454-7
...
7
Dusting Brush - Packaged 54505-3
...
8
Hose Assembly 53594-4
...
9
Floor Tool 39139-1
...
10
Tool - Crevice 27237-3
...
11
Brush Insert 55037

Eureka 3822B

...
...
1
Wheel - Rear 26440-25
...
2
Button - Switch 26649A-14
...
3
Button - Latch 26653-9
...
4
Gasket - Motor Mounting 28032
...
5
Strain Relief Mount 26716-1
...
6
Cord - Low Lead (18 GA) 39630-1
...
7
Caster 37403-1
...
8
Release - Cord 37490-1
...
9
Filter - Motor 37657
...
10
Filter - Exhaust 37710-1
...
11
Sound Foam 37966
...
12
Paper Bag Package Assembly 52358B
...
13
Tie - Cable (Purchased) 46713-5
...
14
Bushing - Strain Relief 53190-1
...
15
Screw Package 53197-1
...
16
Wire Splice 5 60192-1
...
17
Screw Package 53238-8
...
18
Motor Assembly 54551-2
...
19
Bag Cover 54019-10
...
20
Nut - Hex 55446
...
21
Gasket - Motor Stack 55463
...
22
Spring 55794
...
23
Gasket - Shell 58853-1
...
24
Spring 56088
...
25
Thermostat 56146
...
26
Washer 56376
...
...
...
...
