Models

Parts

product name

Electrolux E30MC75JPS1 Wall Oven/Microwave Combo

Model: E30MC75JPS1

Save Part Not Listed?
product name

Electrolux E30MC75JPS1

...
...
1
Wall Oven Microwave Power Cord WCI-5304470537
...
2
Assembly WCI-5304461109
...
3
Microwave Noise Filter WCI-5304498734
...
4
Microwave Door Interlock Switch WCI-5304493153
...
5
Microwave Magnetron Fuse WCI-5304461113
...
6
Microwave Thermal Cut-Off WCI-5304461114
...
7
Microwave Light Bulb WCI-5304464198
...
8
Microwave Light Socket WCI-5304463785
...
9
Oven Motor WCI-5304461119
...
10
Microwave High-Voltage Transformer WCI-5304470538
...
11
Microwave High-Voltage Capacitor WCI-5304470539
...
12
Microwave Rectifier WCI-5304480635
...
13
Microwave Magnetron WCI-5304480636
...
14
Wall Oven Microwave Turntable Motor WCI-5304498736
...
15
Transformer WCI-5304470541
...
16
Microwave Humidity Sensor WCI-5304461125
...
17
Wall Oven Microwave Temperature Sensor WCI-5304483929
...
18
Oven Motor WCI-5304461115
...
19
Oven Motor WCI-5304471782
...
20
Cabinet WCI-5304470542
...
21
Oven Base WCI-5304470734
...
22
Oven Foot WCI-5304461127
...
24
Holder WCI-5304461129
...
25
Oven Hinge WCI-5304482319
...
26
Hinge WCI-5304482320
...
27
Microwave Door Latch Hook WCI-5304470547
...
28
Microwave Latch Body WCI-5304470548
...
29
Microwave Door Hinge Cam WCI-5304480640
...
30
Microwave Door Hinge Cam WCI-5304480641
...
34
Wall Oven Microwave Turntable Tray WCI-5304470563
...
35
Oven Frame WCI-5304461155
...
36
Bracket WCI-5304470564
...
38
Duct Assembly WCI-5304461158
...
39
Microwave Turntable Motor Coupler WCI-5304480644
...
40
Wall Oven Microwave Waveguide Cover WCI-5304461165
...
41
Oven Lens WCI-5304461167
...
42
Blade WCI-5304461173
...
43
Duct WCI-5304461174
...
44
Support WCI-5304461175
...
45
Angle WCI-5304461178
...
47
Guide WCI-5304461181
...
48
Sheet WCI-5304461182
...
49
Oven Cover WCI-5304461183
...
50
Harness WCI-5304461196
...
51
Angle WCI-5304451459
...
53
Spring WCI-5304503732
...
54
Insulator WCI-5304470576
...
55
Bearing Assembly WCI-5304480647
...
56
Plate WCI-5304461147
...
57
Plate WCI-5304461148
...
58
Holder WCI-5304461149
...
59
Plate WCI-5304461150
...
60
Fan Blade WCI-5304461151
...
61
Microwave Convection Fan Pulley WCI-5304471508
...
62
Duct Assembly WCI-5304480648
...
63
Sheet WCI-5304461154
...
64
Cam WCI-5304461159
...
65
Shaft WCI-5304461160
...
66
Microwave Vent Damper Door WCI-5304461161
...
67
Duct WCI-5304461162
...
70
Microwave Cooking Rack WCI-5304461195
...
71
Plate WCI-5304461172
...
72
Pulley WCI-5304461152
...
73
Belt WCI-5304461177
...
74
Cushion WCI-5304461179
...
85
Wire WCI-5304440331
...
86
Wiring WCI-5304461199
...
87
Label WCI-5304440334
...
88
Label WCI-5304465314
...
89
Wall Oven Wire Harness WCI-5304480653
...
90
Label WCI-5304451534
...
91
Label WCI-5304440333
...
92
Label WCI-5304471514
...
93
Screw WCI-5304461379
...
94
Screw WCI-5304451550
...
95
Screw WCI-5304451552
...
96
Wall Oven Screw, M4 X 12 WCI-5304451553
...
97
Screw WCI-5304461203
...
98
Microwave Humidity Sensor Duct Screw WCI-5303319641
...
99
Screw WCI-5304461209
...
100
Screw WCI-5304470587
...
101
Screw WCI-5304461215
...
102
Screw WCI-5304470588
...
103
Screw WCI-5304461221
...
104
Screw WCI-5304470589
...
105
Nut WCI-5304470590
...
106
Screw WCI-5304450253
...
107
Screw WCI-5304461210
...
109
Screw WCI-5304461204
...
110
Screw WCI-5304461208
...
111
Screw WCI-5304471515
...
112
Screw WCI-5304461216
...
113
Nut WCI-5304451547
...
114
Washer WCI-5304461214
...
115
Microwave Door Interlock Switch Actuator, Left WCI-5304470591
...
116
Microwave Door Interlock Switch Lever, Right WCI-5304470592
...
117
Guide WCI-5304480654
...
118
Microwave Turntable Motor Shaft Seal WCI-5304451470
...
119
Cushion WCI-5304482055
...
120
Holder WCI-5304470735
...
121
Microwave Electronic Control Board WCI-5304480656
...
122
Microwave Convection Element WCI-5304474695
...
124
Angle WCI-5304480657
...
125
Angle WCI-5304480658
...
134
Microwave Bacon Rack WCI-5304461261

Electrolux E30MC75JPS1

...
...
NI
Wall Oven Screw, #6-20 X 3/8-In (Black) WCI-5304443263
...
NI
Screw (Black) WCI-5304437044
...
NI
Range Screw WCI-5304436875
...
3
Door Front WCI-318235914
...
8
Wall Oven Door Middle Glass WCI-318238020
...
10
Washer Screw WCI-5304447555
...
16
Wall Oven Door Inner Glass WCI-318237926
...
23
Wall Oven Door Hinge WCI-318244305
...
24
Oven Trim WCI-318390401
...
39
Oven Handle WCI-318392423
...
75
Microwave Door Outer Panel Assembly WCI-5304471511
...
77
Wall Oven Microwave Inner Door Frame WCI-5304470579
...
79
Wall Oven Microwave Door Latch WCI-5304491054
...
80
Wall Oven Microwave Door Latch, Left WCI-5304490142
...
81
Microwave Door Latch Head Spring WCI-5304470582
...
82
Microwave Screw, 4 X 8-Mm WCI-5304451561
...
83
Range Screw WCI-5304470583
...
193
Range Hole Plug WCI-316210800

Electrolux E30MC75JPS1

...
...
NI
Range Screw WCI-5304436875
...
NI
Refrigerator Screw WCI-5303211311
...
NI
Wall Oven Display Wire Harness WCI-318532194
...
NI
Range Screw, #6-32 X 1/4-In WCI-316524400
...
20
Board WCI-316570420

Electrolux E30MC75JPS1

...
...
NI
Wall Oven Wire Harness WCI-5304506955
...
NI
Range Screw WCI-5304461333
...
NI
Range Screw WCI-5304453707
...
NI
Range Screw WCI-5304436875
...
NI
Plate WCI-5304435874
...
NI
Range Screw, 8 X 18 X 0.406-In WCI-5304415832
...
NI
Range Wire Harness Retainer WCI-5304400192
...
NI
Screw (8-18X WCI-5303323277
...
NI
Range Nut WCI-5303323144
...
NI
Range Screw, 10-24 X 0.906-In WCI-5303323139
...
NI
Range Screw, 10 X 24 X 29/32-In WCI-5303323130
...
NI
Screw WCI-5303323129
...
NI
Range Oven Door Trim Double-Sided Tape WCI-5303316982
...
NI
Refrigerator Screw WCI-5303211311
...
NI
Range Screw WCI-5300803416
...
NI
Dishwasher Screw WCI-5300803416
...
NI
Bracket WCI-318373001
...
NI
Wall Oven Bake Element Wire Harness WCI-318231870
...
NI
Oven Clip WCI-318167300
...
NI
Range Lock Washer WCI-316247800
...
6B
Wall Oven Rack WCI-318345405
...
6A
Range Roasting Rack WCI-318365800
...
7
Pin WCI-318368300
...
9
Range Broil Pan WCI-318138801
...
10
Range Broil Pan Insert WCI-316082001
...
12
Range Oven Door Switch WCI-316445501
...
14
Range Oven Rack Sensing Switch WCI-318562200
...
15
Range Oven Light Assembly WCI-139001800
...
18
Bracket WCI-318562300
...
37
Cooking Appliance Oven Temperature Sensor WCI-5304504897
...
53
Range Oven Meat Probe Sensor WCI-5304504202
...
54
Wall Oven Meat Probe Jack WCI-318601206
...
55
Range Nut WCI-316247700
...
57
Wall Oven Service Panel WCI-318361610
...
62
Range Terminal Block WCI-5304409888
...
66
Range Broil Element WCI-318255806
...
67
Range Bake Element WCI-318601604
...
74
Range Door Bumper WCI-316517600
...
77A
Range Power Control Board Support WCI-316114100
...
77
Range Spacer WCI-318293702
...
80
Wall Oven Rear Panel Spacer Bracket WCI-5303320846
...
84
Outlet WCI-318146843
...
86
Range Oven Door Hinge Receptacle WCI-318241406
...
89
Wall Oven Door Lock Assembly WCI-318095965
...
98
Cooking Appliance Screw, 6-18 X 1-In WCI-5304401490
...
107
Range Convection Fan Cover WCI-318906601
...
108
Range Oven Cooling Fan Assembly WCI-318073038
...
108
Wall Oven Cooling Fan Assembly WCI-318073019
...
109
Range Convection Fan Blade WCI-318398302
...
111
Range Convection Fan Blade Nut WCI-316136600
...
125
Range Convection Fan Motor WCI-5304463302
...
129
Range Surface Burner Igniter Spring WCI-5303311164
...
143
Stiffener WCI-318172904
...
161
Element WCI-318255512
...
185
Range Spacer WCI-318531800
...
310
Wall Oven Mounting Kit WCI-5304435864
...
311
Screw WCI-5304438005
...
312
Wall Oven Removal Tool, Left WCI-318246703
...
312
Wall Oven Removal Tool, Right WCI-318246702
...
400
Box WCI-318576901
...
410
Bracket WCI-318933901
