HEX NUT 5/16-18 For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-712-3010
Hex Jam Nut 3/8-24 Thd For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-712-0711
Cotter Pin 1/8" Dia. x 1" For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-714-0115
Hex Patch Bolt 1/4-20 x 1.25" Part of Transmission Complete, Ref. No. 36.
MTD-710-1062
2
L-Wash. 1/4" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0329
3
Upper Hsg. Half Part of Transmission Complete, Ref. No. 36.
MTD-717-0418A
4
#48 Sprocket 7T x 1/2 Pitch Part of Transmission Complete, Ref. No. 36.
MTD-713-0400
5
FLAT WASHER For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0336
6
Hex Flange Brg..631" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-741-0413
7
Hex Bearing Cup For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-16500A-0637
8
Thrust Wash..382" I.D. x .70" O.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-736-0314
9
Thrust Bearing .375" I.D. x .812" O.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-741-0479
Lower Hsg. Half For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-717-0419A
28
Flange Bearing .566 ID For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-941-0415
29
33 Tooth Helical Gear For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-717-0422A
30
Flange Bearing .629 Dia. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-741-0414
31
Oil Seal .625 Dia. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-721-0213
32
Gear Sprocket Shaft For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-738-0607A
33
L-Wash. #10 I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-736-0722
34
Hex Wash. Hd. Self-Tap Scr. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0651
Hex Wash. Hd. B-Tap Scr. 1/4 x .62" (Spec.)
MTD-710-0896
53
Hex Nut 1/4-20 Thd. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-912-0287
