product name

Amana SA2010.002 (BOM: SA2010.00 2)

Model: SA2010.002 (BOM: SA2010.00 2)

Save Part Not Listed?
product name

01 - Page 1

...
...
NI
M95d11-Centigrade Thermo WPL-M95D11
...
1
Outer Case WPL-M80D121
...
2
Back Panel WPL-M82D178
...
3
Lamp, Cavity WPL-M9D54
...
4
Cover Lamp WPL-M7D309
...
5
Lamp Holder WPL-40082P01
...
6
Foot, Outer Case WPL-C8960601
...
7
Stirrer Blade Kit WPL-M35D44
...
8
Insert Stirrer Kit WPL-M2D571
...
9
.187 Dia Push Rivet/bag-25pcs WPL-M1D612
...
10
Poly Button WPL-M1D832
...
11
Screw Plastc (25) WPL-M1D897
...
12
Sensor Magnetron Kit WPL-M4D101
...
13
Cavity Assy WPL-M77D132
...
14
Adhesive WPL-W10841140
...
15
Rack Support Set WPL-M2D601
...
16
Cavity Plug (10) WPL-M1D755
...
17
U-Clip WPL-M2D575
...
18
Toroid (Arc Suppressor) WPL-44780P01
...
19
Ia 5mm Flange Whiz-Lk Nut (25) WPL-M1D619
...
20
Gasket-Rf WPL-M2D296
...
21
Screw Thrm WPL-M1D666
...
22
Screw WPL-WP90767
...
23
No.10-32 Flange Whiz-Lk Nut WPL-M1D449
...
24
Gasket-R.f. WPL-38874P01
...
25
Cap Inner Door Assy Kit WPL-M55D17
...
26
Bkg Plate Assy. WPL-M20D218
...
27
Screw Frame WPL-41327P01
...
28
Door Handle Kit WPL-M11D61
...
29
Insert Kit WPL-M7D588
...
30
Cont Panel Frame WPL-M7D590
...
31
Speed Clip WPL-41657P01
...
32
Rivet, Pop WPL-A4539629
...
33
Fuse, 10 Amp WPL-M0805106
...
34
No.4-40 Twin Whiz-Lock Nut WPL-M1D360
...
35
Nut WPL-WP488130
...
36
Nut WPL-WP488130
...
37
Nut WPL-WP488130
...
38
Capacitor-Doubler WPL-10366913
...
39
Screw WPL-WP90767
...
40
Nut K WPL-M0282005
...
41
Screw (25) WPL-M1D903
...
42
Fan Blade WPL-M35D40
...
43
Blower Duct Assembly WPL-M65D283
...
44
No.8-32 Hex Nut Jw (25) WPL-M1D84
...
45
Bush, Strain Relf (10) WPL-M2D586
...
46
H.v. Xfmr WPL-M60D134
...
47
H.v. Lead Kit WPL-M5D350
...
48
Knob, Timer/controller WPL-M6D298
...
49
M7d764 Dec Pnl Assy. WPL-42624P02
...
50
Not Available WPL-M7D592
...
51
Not Available WPL-M8D253
...
52
Pct Timerx WPL-30001P02
...
53
Timer 30 Min WPL-M30D86
...
54
Frame WPL-M7D637
...
55
Surge Resistor WPL-M3D36
...
56
Screw WPL-WPW10068250
