Amana EX2485.A

Model: EX2485.A

Save Part Not Listed?
product name

01 - Page 1

...
...
NI
Menu Guide WPL-M94D512
...
1
Outer Case WPL-M80D121
...
2
Lamp, Cavity WPL-M9D54
...
3
Lamp Holder WPL-40082P01
...
4
Screw WPL-WP90767
...
5
Screw WPL-WP90767
...
6
Foot, Outer Case WPL-C8960601
...
7
Stirrer Blade Kit WPL-M35D44
...
8
Ball WPL-38321P01
...
9
Support-Stir WPL-M20D236
...
10
Poly Button WPL-M1D832
...
11
Screw Plastc (25) WPL-M1D897
...
12
Fuse- Ther WPL-59001951
...
13
Cavity Assy WPL-M77D132
...
14
Adhesive WPL-W10841140
...
15
Rack Support C-Type Wht WPL-3010010002
...
16
Support Rack WPL-B8371001
...
17
Screw WPL-WP98165
...
18
Ia 5mm Flange Whiz-Lk Nut (25) WPL-M1D619
...
19
Gasket-Rf WPL-M2D296
...
20
Screw Thrm WPL-M1D666
...
21
Screw WPL-WP90767
...
22
Inner Door-Brown WPL-M70D127
...
23
Gasket-R.f. WPL-38874P01
...
24
Cap Inner Door Assy Kit WPL-M55D23
...
25
Kit, Latch Hook WPL-M2D739
...
26
Outer Door Assembly WPL-M70D143
...
27
Handle Asy WPL-M11D79
...
28
Cont Pnl Frame WPL-M7D813
...
29
Rack (White) Kit WPL-M67D32
...
30
Rivet, Pop WPL-A4539629
...
31
Fuse, 10 Amp WPL-M0805106
...
32
Ia Screw WPL-M1D329
...
33
Kit, Diode WPL-M3D71
...
34
Foot WPL-M2D179
...
35
Cap & Diode Kit WPL-M10D143
...
36
Bracket WPL-10825501
...
37
Nut K WPL-M0282005
...
38
Bracket Blower WPL-M20D219
...
39
Fan Blade WPL-M35D40
...
40
Screw WPL-WP90767
...
41
Pwr Cord WPL-M26D36
...
42
Bush, Strain Relf (10) WPL-M2D586
...
43
No.10 T X 3/8`` Screw WPL-M1D479
...
44
Wire Pkg Assy WPL-M27D390
...
45
Touch Panel Assembly WPL-M7D846
...
46
Display Window WPL-M2D722
...
47
Net-Assy,ckt Bd(Rework) WPL-M32R51
...
48
Screw WPL-WP90767
...
49
Nut K WPL-M0282005
...
50
Screw, Tf WPL-M0231704
...
51
Baffle Cav Upper WPL-M65D337
...
52
3/8 Int Tooth Lockwasher WPL-M1D598
...
53
Rivet, Pop WPL-A4539629
...
54
Wire Clip (10) WPL-M2D741
...
55
Screw (25) WPL-M1D590
...
56
Probe-Temp WPL-45584P01
...
57
Varistor Asm WPL-M3D49
...
58
Toroid (Arc Suppressor) WPL-44780P01
...
59
Line Filter Kit WPL-M10D90
