Amana AKC-1B (BOM: P8512305S)

Model: AKC-1B (BOM: P8512305S)

Save Part Not Listed?
product name

01 - Page 4

...
...
NI
Usr 0041847 WPL-M0282402
...
1
Knob Control K WPL-D8572402
...
2
Bushing WPL-A4402501
...
3
Cover Assy A WPL-D8503501
...
4
Screw, 6-18 X 3-8b WPL-M0216501
...
5
Light-Indicator A WPL-C2702601
...
6
Nut WPL-WP7103P070-60
...
7
Insulation, Ind. Light WPL-A4402901
...
8
Thermostat, Essex WPL-D8503901
...
9
Switch- In WPL-R0702564
...
10
Wick-Felt A WPL-A4402601
...
11
Bracket WPL-B5001701
...
12
Screw WPL-M0202514
...
13
Terminal Block A WPL-A4403401
...
14
Cover WPL-D8503101
...
15
Channel WPL-B5001401
...
16
Channel WPL-B5001301
...
17
Insulation, Door Plug WPL-B5001101
...
18
Insulation Kit WPL-R0157513
...
19
Insul-Lo-Con K WPL-C2702001
...
20
Wiring Harness WPL-D8503801
...
21
Conduit Cap A WPL-A4403101
...
22
Bracket WPL-A4403301
...
25
Wire Splice WPL-A4403201
...
26
Hld Down Assy WPL-C2701701
...
27
Bar WPL-C2702501
...
28
Element Kit, Large WPL-R0157502
...
29
Element Kit, Small WPL-R0157501
...
30
See Svc Ltr Cba-136 WPL-D8527201
...
31
See Serv Ltr Cba-136 WPL-C2702401
...
32
Control Box Assembly WPL-D8524001
...
33
Seal-Shaft A WPL-B5001601
...
34
Glass, Control Panel WPL-D8520802
...
35
Htr Box WPL-D8502801
...
36
Clip-Htr Box WPL-B5001501
...
38
Net-Kit,heater Panel WPL-R0157515
...
39
Frame WPL-D8504502
...
40
Switch WPL-C2703201
...
41
Cover Assy A WPL-D8503501
...
42
Tape, Vinyl Foam, Roll WPL-M0275028
...
43
Spring, Element WPL-74008213
...
44
Screw (3) WPL-67006425
...
45
Screw WPL-WP90767
...
46
Clip-Retainer WPL-A4411901
...
47
Element Kit, Small WPL-C2711001
...
48
Screw WPL-W10856125
