42539A Murray - Lawn Tractor (1998)

Model: 42539A

Back To Assemblies

Save Part Not Listed?
product name

Popular Parts

Popular Parts

Mower Housing Suspension

...
...
1
GRIP BS-1753233YP
...
2
Handle, PTO BS-094100 Z
...
3
Pad, Switch BS-094022 Z
...
4
Screw, Hex BS-0025X3MA
...
5
GRIP BS-1753233YP
...
6
Spring BS-166X40MA
...
7
Washer BS-17X103MA
...
8
Lever, Lift BS-094195 Z
...
9
Lever, PTO BS-094017 Z
...
10
Bolt, Shoulder BS-009X39MA
...
11
PIN, COTTER, 3/32X.75 BS-703312
...
12
Washer BS-017X57MA
...
13
Link, PTO BS-094004 Z
...
14
NUT, CNTR LCK, 3/8-16 BS-703893
...
15
Screw BS-26X249MA
...
16
Spring BS-166X39MA
...
17
Bracket, PTO BS-094018E701MA
...
18
Spring BS-165X119MA
...
19
Crank, PTO BS-94019E700
...
20
Link, Left Lift BS-094611E701MA
...
21
Link, Lift BS-094028 Z
...
22
Bolt BS-001X74MA
...
23
Screw BS-026X49MA
...
24
PIN, 3/32 X 1.6 BS-703300
...
25
Washer BS-017X91 Z
...
26
LIFTER LINK, RIGHT BS-094053E701MA
...
27
Lever Assembly, Lift BS-094180E700
...
28
NUT, 5/16-24 Hex Flange Lock, BZ BS-704279
...
29
Plate, Lift Arm BS-094030E700
...
30
PIN, 3/8-16 BS-704054
...
31
Bracket, Rear Suspension BS-094055E701MA
...
32
Bushing BS-094065MA
...
33
Bolt, Shoulder BS-009X53MA
...
34
Bracket, Pivot BS-094015E700
...
35
Tube, Deck Lift BS-094063E700
...
36
Washer BS-17X191MA
...
37
NUT, CNTR LCK, 3/8-16 BS-703893
...
38
Spring BS-165X117MA
...
39
NUT, 3/8-16 BS-703333
...
40
Bracket, PTO BS-094005E700
...
41
Hanger, Left Deck BS-094027E701MA
...
42
Hanger, Right Deck BS-094026E701MA
...
43
Rod, Hanger BS-094158ZMA
...
44
BRKT-FRT SUSPENSION BS-690539E701MA
