42502x8C Murray - Lawn Tractor (2000)

Model: 42502x8C

Back To Assemblies

Save Part Not Listed?
product name

Mower Suspension Assembly

...
...
1
HAIR PIN BS-711676
...
8
LINK, LIFT LH BS-94611-821
...
9
LINK-LIFT BS-94053-821
...
10
FLATWASHER BS-711617
...
11
PIN, HAIR BS-711676
...
13
WASHER, FLAT BS-711617
...
14
PIN, HAIR BS-711676
...
19
LINK LIFT HANDLE BS-95285
...
20
WASHER, FLAT BS-711617
...
21
PIN, HAIR BS-711676
...
22
GRIP .50 DELUXE- BLAC BS-094497MA
...
23
HANDLE, LIFT BS-690532
...
24
WASHER, FLAT .550 x 1.00 x 11 BS-711616
...
25
TORSION SPRING,.657LG BS-710111
...
26
GRIP BS-1753233YP
...
27
HANDLE, PTO BS-690126
...
28
PADDLE-SWITCH BS-094022ZMA
...
29
SCREW, THD FORM .246X1.050LG BS-711621MA
...
30
BRACKET, PTO BS-94018-821
...
31
SCREW, 5/16-18X.5 BS-703985
...
32
LEVER, PTO BS-95283MA
...
33
BOLT, .50X.75 HHSH 3/8-16 BS-711613MA
...
34
PIN, HAIR.072 DIAX1.13LG BS-711659
...
35
WASHER, FLAT .518 x .87 x 16 BS-711615MA
...
36
LINK PTO BS-95282
...
37
NUT, 3/8-16 HWDFLLK MACK BS-711622
...
38
SCREW, 5/16-18 x 0.75 HHWATAP BS-711606MA
...
39
TORSION SPRING.33LG BS-710141
...
40
SPRING, TENSION 1.010D 8.18LG BS-710311
...
41
EXTENSION SPRING BS-710208
