1509-3 Briggs and Stratton Portable Generator G-Force 1400

Model: 1509-3

Back To Assemblies

Save Part Not Listed?
product name

Alternator & Outlet Panel

...
...
1
FAN COVER SOGA 1.2KW BS-102593GS
...
2
FAN SOGA 1.2KW BS-102594GS
...
3
STATOR ASSEMBLY SOGA1.2KW BS-102595GS
...
4
BEARING ROTOR TEKEL1KW BS-102575GS
...
5
ROTOR ASSEMBLY SOGA1.2KW BS-102596GS
...
6
STU D3/8"UNF'1.5" BS-102597GS
...
7
FLANGE PLATE SOGA 1.2KW BS-10259BGS
...
8
CAPACITOR 40UF BS-102293GS
...
9
SOCKET OUTLET BS-102030GS
...
10
ALTERNATOR SOGA 1.2KW VERTICAL BS-102570GS
Schematic Image Zoomed
