Weed Eater 670 Gas Trimmer

Model: 670 Gas Trimmer

Save
 Part Not Listed?Part Not Listed?
product name

CUTTING HEAD ASSEMBLY

...
...
1
Head Assembly PLN-530092809
...
2
Hub PLN-530092802
...
3
Spool w/Line PLN-952701510
...
4
Spring, Spool Retainer PLN-530092805
...
5
Lower Cover PLN-530092806
...
6
Socket Head Cap Screw 3/8 NC x 1-1/4 PLN-530092808
...
7
Arbor Post PLN-530092803
...
8
Retainer, Line PLN-530092807
...
9
Shoulder Strap PLN-530092779
...
10
10" Brush Blade (Optional) PLN-952701598
...
11
8" -Model 670 PLN-952701527
...
11
11" -Models 650,657 PLN-952701509

DRIVE SHAFT & CUTTING HEAD

...
...
2
GASKET DIAPHRAGM KAAZ # PLN-110092835
...
xx
Motor Leg Assembly PLN-530092835
...
3
Motor Adaptor Plate PLN-530092836
...
4
Lock Washer PLN-530091458
...
5
Screw PLN-530092833
...
6
Clutch Spacer PLN-530092758
...
7
Clutch Assembly (Incl. #8, 9, 10 & 11) PLN-530092759
...
8
Clutch Shoe Assembly PLN-530093131
...
9
Clutch Spring PLN-530092762
...
10
Clutch Hub PLN-530092763
...
11
Woodruff Key PLN-530092764
...
12
Lock Washer PLN-530091458
...
13
Screw PLN-530092766
...
14
Clutch Drum Assembly PLN-530092837
...
15
Ball Bearing, Lower PLN-530092769
...
16
Screw PLN-530092833
...
17
Clutch Housing w/Bearing & Bushing PLN-530092838
...
18
Screw PLN-530092839
...
19
Clutch Bushing PLN-530092841
...
20
Screw PLN-530092842
...
21
Drive Shaft Washer PLN-530092773
...
22
End Coupling PLN-530092774
...
25
Screw PLN-530092787
...
26
Handle Bar (Ieft) PLN-530092845
...
27
Handle Grip PLN-530092846
...
28
Handle Bar Clamp PLN-530092847
...
30
Flexible Drive Shaft PLN-530092776
...
31
Drive Shaft Housing PLN-530092849
...
32
Neoprine Guide PLN-530092851
...
33
Drive Shaft Housing PLN-530092852
...
34
Throttle Control Clip PLN-530092853
...
35
Throttle Control Complete PLN-530092789
...
36
Tank, Fuel PLN-530092862
...
37
GASKET KAAZ # PLN-110092854
...
xx
Upper Bearing PLN-530092854
...
38
Screw PLN-530092833
...
39
Lower Housing PLN-530092855
...
40
Blade Guard PLN-530092856
...
41
Filler Plate PLN-530092857
...
42
Screw PLN-530092858
...
43
Weed Deflector Cup PLN-530092859
...
44
Cap, Fuel Tank PLN-530092746
...
45
Baffle, Fuel Tank PLN-530092863
...
46
Clip, Fuel PLN-530092752
...
47
Hose, Fuel PLN-530092864
...
49
Fitting, Fuel PLN-530092866
...
50
Washer, Lower Arbor PLN-530093137
...
51
Washer PLN-530093153
...
52
Nut, Hex - 7/16 - 20 PLN-530093139
...
...
...
