You are here: Home > ORECK > Oreck Upright Vacuums > Oreck U2000RB
Oreck U2000RB Upright Vacuum Model: U2000RB Add to My Models
Popular Parts:
Bag Paper Blue With Out Docking 9 Pack PK80009
Bag Paper Green With Out Docking 9 Pack PK80009DW
Brush Roll, Permanent Belt 7588101
Drive Belt, Single Permanent 7585501
U2000RB

U2000RB

02. Cord Clamp Foot Switch Units 030061301
02. Cord Clamp D-Handle Units 030061901
03. Screw, #8 - 32 x .440 Nylock Handle Tube 030047802
03. Screw, #8 x .811 w/ Int Washer Handle Tube w/Through Bolt 030060801
03. Screw, #8-32 X .545 w/ Washer Handle Brace 030050402
03. Screw, #8 - 32 x 29/32 w/ Washer Handle Brace w/Through Bolt 030060501
04. Bag Retainer Spring 7503502
05. Bag Paper Blue With Out Docking 9 Pack PK80009
05. Bag Paper Green With Out Docking 9 Pack PK80009DW
05. Dust Bag, (25 Pk.) PK800025DW
06. Outer Bag 7524616
07. Bag Clip Assembly 097507808
08. Connector Assembly Kit, includes items #3 & #84 097530857
09. Collar 75199020327
10. Tube Assembly 7519805
12. Fan Housing Assembly includes Rivet & Spring 097522112
15. Screw, #8 X .5 Phillips Headlight Cover, Bulb Holder, Foot Switch, Cable Clamp 0375201
16. End Cap 0134623
18. METAXALLOYâ„¢ Fan Kit w/Washers 097530001
19. Fan Seal Cup 7501201
20. Cord 7555804441
26. Top Cover w/Belt Door Assembly (Incl. mylar label & strain relief) 097543020
27. Bumper, Clear 7518104
28. Intake Pivot Assembly with Felt Seal 097506602
29. Felt Seal 7506501
30. 1/4 X 32 Yellow Chrome Fan 030044801
32. Felt Seal, Motor 7511701
33. Strain Relief 030049401
34. Motor Assembly Kit 097550502
35. Motor Seal 7509501
36. Kit, Motor Brush (Large & Small) / Spring 097551401
38. Screw, #8 X .75 Phillips D-Handle (small head) 030045601
38. Screw, #8 x .75 D-Handle Type 6 & 7 Only 030047601
39a. Drive Belt, Single Permanent 7585501
40. Door Belt, Red Vented 7589401441
42. Brush Roll, Permanent Belt 7588101
41. Wire Nut 030059901
43. Seal, Baseplate 7500801
44. Plastic Detent, (uses 2 #49 screws) 7529901
45. Complete Baseplate Assembly Commercial Vented 097590001
46. MICRO SWEEP Blade 7570002
47. Channel 7570101
48. Screw, #8 x .75 Phillips Baseplate, Belt Door, Intake Pivot, Motor 030047601
49. Screw, #7 X .38 Phillips Edge Brush Type 1-6 Only, Detent 030047501
50. Edge Brush, Silver ION 7576603
51. Wheel Axle 030063001
52. Soft Rear Wheel, Black 75187020327
54. Single Speed Switch 7555901
55. Grips, Red Set Hardwire Handle 097557608
60. Motor Spring 7528301
61. Tube Label 7508705
63. Screw, #10 x .5 Phillips Cord Bracket 030045001
65. Mylar Label 7559911
68. Screw, #6-20 x 1/4' Collar Type 1& 2 Only 030048201
69. O-Ring Collar 7519102
72. Washer, Thrust Fan 030047901
73. Washer, Lock External Tooth Fan 030048001
74. 1' x 3', Loop Fastener Bag Support 7530401
75. 1' x 1', Hook Fastener Bag Dock 7530301
76. Handle Brace 7543201
76a. Handle Brace Kit 7543501
77. Retainer Clip Baseplate Type 1-6 Serviceable 03528
78. Wireform Baseplate Type 1-6 Serviceable 7519403
79. Stiffener (uses same length screws, notched) 7518902
79. Stiffener, Through Bolt Connector (uses different length screws) 7561901
81. Cord Flex Relief 030060001
82. Steel Bushing Ring D-Handle 030059801
84. Nut, Square Connector 030060601
85. Screw, #6-20 x 7/16 Flat Undercut Edge Brush, Channel Type 7 Only 030062601
86. Wireform, One-Piece BaseplateType 7 Only 7569801
87. Wheel and Tire Overmolded 7570901
88. JST Insulator Harness 7567901
89. Rivet Fan Housing 030045301
90. Bag Spring Fan Housing 7501501
91. Push Nut Fan Housing 030063601
92. Bag Stiffener 76061010327
93. PCB/Footswitch Bracket 75880010327
94. Main Circuit Board 7587902
95. Circuit Board Harness 7587802
96. Wire Harness 7587701



-xx. = Not shown on schematic.

Sort By:
Page of 7
Oreck Metaxalloy Fan Oreck Axle, Front & Rear Wheel.  Manufacturer's Model/Part Number: 030063001
Oreck Metaxalloy Fan #097530001
List Price $20.98
Sale Price $17.48
You save $3.50!
Oreck Axle, Front & Rear Wheel #030063001
List Price $3.12
Sale Price $2.60
You save $0.52!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Oreck 2000 Series Tube Assembly Type 5&6 Oreck Wheel, Rear.  Manufacturer's Model/Part Number: 75187020327
Oreck 2000 Series Tube Assembly Type 5&6 #7519805
List Price $17.36
Sale Price $14.47
You save $2.89!
Oreck Wheel, Rear #75187020327
List Price $3.94
Sale Price $3.28
You save $0.66!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Oreck Motor Oreck Connector Assembly 3000 Series
Oreck Motor #097550502
List Price $91.36
Sale Price $76.13
You save $15.23!
Oreck Connector Assembly 3000 Series #097530857
List Price $16.56
Sale Price $13.80
You save $2.76!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Oreck One Speed Switch Type 6/7 Comm Oreck Felt Seal.
Oreck One Speed Switch Type 6/7 Comm #7555901
List Price $10.25
Sale Price $8.54
You save $1.71!
Oreck Felt Seal. #7506501
List Price $4.69
Sale Price $3.91
You save $0.78!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Oreck Felt Washer Motor Seal Oreck Pivot And Seal
Oreck Felt Washer Motor Seal #7511701
List Price $2.64
Sale Price $2.20
You save $0.44!
Oreck Pivot And Seal #097506602
List Price $7.07
Sale Price $5.89
You save $1.18!
Usually ships Same Day / Next Day Usually ships within 3 days
