You are here: Home > More Top Brands > Eureka > Eureka Upright Vacuum Parts > 2059 Eureka Upright

U9145

Eureka 2059 Upright. Model: 2059- Add to My Models 2059A

U9145

01. Lens - Hood 12601-8
02. Switch Assembly 13738-5
03. 24834A-1 Discontinued, use 24834A-3 24834A-3
xx. Cam (Right) 24964A
xx. Cam (Left) 24965A
06. Tie - Cable (Purchased) 26307
07. Gasket - Motor Seal 30517
08. Headlamp Socket Assembly 35958A
09. Cover - Wheel 36263
10. Knob Assembly 38053-2
11. Lamp - Headlight 40009A
12. Base Assembly 49063-26
13. Spring - Foot Pedal Package 53097
14. Spring - Hood Package -10 53117
xx. Rivet - Shoulder Package 53118
16. Steel Washers (48495 FNLA
17. Clamp & Screw Assembly 53140
18. Screw Package -10 53143
19. Wire Nuts - Pack of 10 53214-1
20. Screws - Package 10 53228-7
21. Screw Package 53238-13
22. Screw Package 53238-14
23. Screw Package 53238-17
24. Wire & Terminal Assembly 55296
25. Nut - Hex 55446
- xx. = Not shown on schematic.

U9145

01. Upper Motor Fan-Lexan 12988-1
02. Assembly - Cartoned 13355-1FIELD
03. Cover - Motor 13746-1
04. Motor Brush Assembly 26055
05. Bearing Retainer Assembly- Without Bearing 42875
06. Rivet Package 51108A-10
07. Screw Package -10 53131-1
08. Washer - Fan Package -10 53148
09. Washer Package 53188

U9145

01. Tube - Disturbulator 13236-1
02. Cap - Disturbulator 25759A
03. Disturbulator Assembly - Cart 25763-1
04. Bottom Plate Assembly 25922-1
05. Discontinued, Use 35858-2 35858-1
06. Axle - Front 35947A
07. Guard - Furniture 36999-4
08. Dist Shaft Assembly 37378
09. Tape-Foam (Use 46538-4) 46538
10. Axle - Rear 47562
11. 52282-3 Discontinued, Use 52282-4 52282-4
12. Spring & Axle Package -6 53076-2
13. Clip Package - 5 53111
14. Lock Nut Package 53158
15. Washer - Shaft Package 53167
16. Screw Package 53238-11

U9145

01. Connector - Handle Tube 25988-2
02. Handle Assembly (Upper) 25989-3
03. Cord - Low Lead (18 Ga) 34732-14
04. Cap - Handle 36873-2
05. Handle Kit - Upright 36984-2
06. Handle Socket & Foot Pedal 52363-2
07. Pin - Snap Package -5 53080-1
08. Bushing & Strain Relief 53089-1
09. Bolt Package - 10 53145
10. Handle Screw Assembly Package 53198-1
11. Screw Package 53238-13
12. Nuts - Package 10 EW14-10ZP

U9145

01. Zipper Bag Assembly - Pkg 13450-33
02. Spring - Bag 47722
xx. Spring - Garter 48410
xx. Wire - Tie 48801
05. Adapter - Bag 54175-1
06. Paper Bag Assembly Style 52320
07. Gasket - Bag Adapter 55106
08. Hardware Package 55123A
- xx. = Not shown on schematic.
Sort By:
Page of 5
Eureka Electrolux Sanitaire Switch 2034A & 2034B 3/8&quote Eureka Electrolux Sanitaire Gasket Upright Motor
Eureka Electrolux Sanitaire Switch 2034A & 2034B 3/8" #13738-5
Our Price: $6.20
Sale Price: $5.17
You save $1.03!
Eureka Electrolux Sanitaire Gasket Upright Motor #30517
Our Price: $4.24
Sale Price: $3.53
You save $0.71!
Usually ships within 3 days Usually ships Same Day / Next Day
Eureka Electrolux Sanitaire Brush Strip Vgii 12&quote Pr Eureka Electrolux Sanitaire Spring Hood
Eureka Electrolux Sanitaire Brush Strip Vgii 12" Pr #52282-4
Our Price: $5.99
Sale Price: $4.99
You save $1.00!
Eureka Electrolux Sanitaire Spring Hood #53117
Our Price: $14.94
Sale Price: $12.45
You save $2.49!
Usually ships Same Day / Next Day Usually ships within 7 days
Eureka Electrolux Sanitaire Washer For Lexan Fans Eureka Electrolux Sanitaire Screw & Nut
Eureka Electrolux Sanitaire Washer For Lexan Fans #53148
Our Price: $4.27
Sale Price: $3.56
You save $0.71!
Eureka Electrolux Sanitaire Screw & Nut #53198-1
Our Price: $4.08
Sale Price: $3.40
You save $0.68!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Eureka Electrolux Sanitaire LENS, 7 3/4" X 1 3/4" 4 TAB UPRIGHTS. Manufacturer's Part Number: 12601-8 Motor Cover, W/O Ball Brg 5.5/6.5 Amp Ultra Metal
Eureka Electrolux Sanitaire LENS, 7 3/4" X 1 3/4" 4 TAB UPRIGHTS #12601-8
Our Price: $12.44
Sale Price: $10.37
You save $2.07!
Motor Cover, W/O Ball Brg 5.5/6.5 Amp Ultra Metal #13746-1
Our Price: $7.80
Sale Price: $6.50
You save $1.30!
Usually ships within 3 days This product is no longer available
Eureka Electrolux Sanitaire AXLE, FRONT SANITAIRE. Manufacturer's Part Number: 35947A Eureka Electrolux Sanitaire HEADLIGHT SOCKET, SC888. Manufacturer's Part Number: 35958A
Eureka Electrolux Sanitaire AXLE, FRONT SANITAIRE #35947A
Our Price: $9.26
Sale Price: $7.72
You save $1.54!
Eureka Electrolux Sanitaire HEADLIGHT SOCKET, SC888 #35958A
Our Price: $10.86
Sale Price: $9.05
You save $1.81!
Usually ships within 3 days Usually ships within 7 days
