Hex Nut 3/8-16 Thd. For faster service obtain standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by P/N and size as shown on parts list.
MTD-712-0798
L-Wash. 3/8" I.D. For faster service obtain standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by P/N and size as shown on parts list.
MTD-736-0169
Hex Nut 3/8-16 Thd. For faster service obtain standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by P/N and size as shown on parts list.
MTD-712-0798
Pan Hd. Scr. #12 x 3/4" Lg. Electric start models only.
MTD-710-1220
75
SPRING WASHER BELL Electric start models only.
MTD-736-0270
76
Battery Charger Electric start models only.
MTD-925-0727
77
HEX NUT 1/4-20 Electric start models only.
MTD-912-0287
?78
L-Wash. 1/4" I.D. Electric start models only. For faster service obtain standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by P/N and size as shown on parts list.
MTD-936-0329
