Troy-Bilt TB25HT 41AD25HT766 Gas Trimmer

Model: TB25HT 41AD25HT766

Save
 Part Not Listed?Part Not Listed?
product name

Engine Assembly

...
...
1
REAR ENGINE COVER (Incl. 2 & 3) MTD-753-10406
...
2
SCREW #10-24X11/16 T-25 MTD-791-182195
...
3
SCREW 8-16 x 3/4 MTD-710-04194
...
4
SHORT BLOCK 25cc (Incl. 2 & 5 - 11) MTD-841P014182S
...
5
SPARK PLUG MTD-753-06847
...
6
O-RING SEAL CYLINDER MTD-753-09085
...
7
SCREW 5/16-18x3/4 T40 MTD-710-06241
...
8
FLYWHEEL ASSEMBLY MTD-753-09125
...
9
BELL WASHER MTD-753-06247
...
10
SPACER :2.165" MTD-750-04434
...
11
MODULE MTD-753-10464
...
12
INTAKE ASSEMBLY (Incl. 13 & 14) MTD-753-09105
...
13
O-RING MTD-753-06184
...
14
CARBURETOR SEAL MTD-721-04972
...
15
CARBURETOR MTD-753-06288
...
16
GASKET CARB MTD-753-06253
...
17
AIR CLEANER (Incl. 18) MTD-753-10484
...
18
AIR FLITER MTD-753-06417
...
19
FUEL TANK ASSEMBLY (Incl. 20 & 21) MTD-753-06183
...
20
FUEL CAP ASSEMBLY MTD-791-182612
...
21
SCREW:10-6 x .75 MTD-791-181930
...
22
SMALL CLUTCH ASSEMBLY W/SMALL DRUM MTD-753-05860
...
23
STARTER HOUSING (Incl. 2 & 24) MTD-753-10644
...
24
NUT, TINNERMAN U-T MTD-791-182366
...
25
CLUTCH COVER (Incl. 3) MTD-753-10405
...
26
SCREW, 8-32 x .312 P MTD-791-182519
...
27
SCREW:CLMPNG W/NUT MTD-753-04291
...
28
HEX NUT MTD-712-0161
...
29
THROTTLE CABLE MTD-746P06311A
...
30
LEAD WIRES MTD-794-00244
...
31
MUFFLER MTD-841P014184S
...
32
CRANKCASE COVER (Incl. 33) MTD-841P014301S
...
33
O-RING SEAL CRANKCASE MTD-753-09086
...
34
WOODRUFF KEY #403-.125 x .375 MTD-914-04016

Gearbox & Blade

...
...
45
GEARBOX ASSEMBLY (Incl. 46 - 53) MTD-753-08000
...
46
BLADE ASSEMBLY (Incl. 47) MTD-753-05623
...
47
BLADE HARDWARE MTD-753-08001
...
48
LOCKING LEVER PIN MTD-753-08002
...
49
SPACER DETENT SHM MTD-753-08003
...
50
CAM MTD-753-08004
...
51
NUT 5/16-24 MTD-753-08005
...
52
SHAKE PROOF WASHER MTD-936-0271
...
53
SCREW - 10-24X.625 PAN HEAD MTD-3434
...
54
SCREW 8-32X.437 MTD-7039
...
55
BOOM ASSEMBLY MTD-753-08007
...
56
BLADE COVER MTD-753-08006
...
57
SCR, M5 x 15.8MM MTD-9054

Throttle

...
...
35
THROTTLE GRIP ASSEMBLY (Incl. 36 - 39) MTD-753-08344
...
36
LEVER LOCK OUT MTD-731-08433C-10
...
37
SW, MOMENTARY ON/O MTD-791-182405
...
38
TRIGGER SPRING MTD-753-05007
...
39
THROTTLE TRIGGER MTD-731-04970B-10
...
40
BOOM ASSEMBLY UPR MTD-753-06880
...
41
D-HANDLE (Incl. 42) MTD-753-08042
...
42
BOLT 1/4-20X1 1/2 MTD-753-06040
...
43
SPLIT BOOM COUPLER KIT (Incl. 44) MTD-753-1190
...
44
SCREW, 10-32X.250 TA MTD-791-182057
...
...
...
