product name

Tecumseh SBV-SBV-2302 4-Cycle Short Blocks Vertical

Model: SBV-SBV-2302

Save
 Part Not Listed?Part Not Listed?
product name

Engine Parts List #1

...
...
1
CYLINDER TPC-34908A
...
2
PIN TPC-27652
...
14
WASHER TPC-28277
...
15
GOVERNOR ROD TPC-35082
...
16
GOV LEVER TPC-32651
...
17
CLAMP TPC-31335
...
18
SCREW TPC-651018
...
19A
SPRING TPC-34043
...
20
OIL SEAL TPC-32630
...
125
EXH VALVE STD TPC-27878A
...
126
INT VALVE ST TPC-34035
...
149A
INT VALVE SEAL TPC-35862
...
149
VALVE CAP TPC-27882
...
150
VALVE SPRING TPC-27881
...
151
VALVE CAP TPC-32581
...
169
GASKET TPC-27896A
...
370
DECAL TPC-36261
...
370A
DECAL TPC-34028

Engine Parts List #2

...
...
30
CRANKSHAFT TPC-34181A
...
40
PISTON ASSY 020 TPC-34862A
...
40
PISTON ASSY STD TPC-34860A
...
40
PISTON ASSY 010 TPC-34861A
...
41
PISTON & PIN 10 TPC-34864
...
41
PISTON & PIN 20 TPC-34865
...
41
PISTON & PIN ST TPC-34863
...
42
PISTON ASSY STD TPC-34866A
...
42
RING SET 020 TPC-34868A
...
42
RING SET 010 TPC-34867A
...
43
RET RING TPC-27888
...
45
CONN ROD--Discontinued TPC-32591C
...
46
SCREW TPC-650662C
...
48
VALVE LIFTER TPC-34034A
...
50
CAMSHAFT TPC-34040
...
52
OIL PUMP TPC-31356
...
69
GASKET TPC-37342
...
70
MTG FLANGE TPC-33580
...
72
PIPE PLUG TPC-31927
...
75
OIL SEAL TPC-31950
...
80
GOV SHAFT TPC-30668
...
81
WASHER TPC-651080
...
82
GEAR TPC-30591
...
83
GOV SPOOL TPC-30588A
...
84
RET RING TPC-29193
...
86
SCREW TPC-650833
...
88
SPACER TPC-31707A
...
108
GROOVE PIN TPC-29783
...
109
GEAR TPC-33245
...
224
GASKET TPC-27915A
...
311
FILLER PLUG TPC-27625
...
312
GASKET TPC-29673

Engine Parts List #4

...
...
16
GOV LEVER TPC-32651
...
19A
SPRING TPC-34043
...
...
...
