product name

MTD MTD5520 41BY85AR978 Gas Chainsaw

Model: MTD5520 41BY85AR978

Save
 Part Not Listed?Part Not Listed?
product name

Engine Assembly

...
...
1
Muffler Screw MTD-753-06397
...
2
Muffler Assembly (Incl. 1, 3 & 19) MTD-753-06268
...
3
Muffler Gasket MTD-753-06398
...
4
Spark Plug MTD-753-06269
...
5
Cylinder Assembly (Incl. 6, 8 & 10) MTD-753-06742
...
6
Cylinder Gasket MTD-753-06400
...
7
Piston Assembly MTD-753-06743
...
8
Cylinder Hardware MTD-753-06402
...
9
Breather Hose w/clamp MTD-753-06726
...
10
Isolator Assembly MTD-753-06404
...
11
Insulator Assembly MTD-753-06727
...
12
Carburetor Gasket MTD-753-06406
...
13
Carburetor MTD-753-06728
...
14
Boot & Bracket Assembly (Incl. 16 & 17) MTD-753-06385
...
15
Carburetor Hardware MTD-753-06410
...
16
Grommet MTD-753-06411
...
17
Throttle Cable MTD-753-06409
...
18
Shortblock Assembly (Incl. 4-10) MTD-753-06744
...
19
Muffler Plug MTD-753-06507

General Assembly

...
...
1
Housing Assembly (Incl. 2, 41 & 42) MTD-753-06730
...
2
Primer Bulb Assembly MTD-753-06425
...
3
Flywheel Assembly MTD-753-06426
...
4
Flywheel Nut MTD-753-06427
...
5
Chain Brake Assembly MTD-753-06386
...
6
Engine Mount Screw MTD-753-06429
...
7
Starter Housing Assembly MTD-753-06430
...
8
Engine Mount Plate Assembly (Incl. 6) MTD-753-06431
...
9
Module Assembly MTD-753-06432
...
10
Clutch MTD-753-06449
...
11
Clutch Drum Assembly MTD-753-06450
...
12
Oil Pump Shield MTD-753-06451
...
13
Bar MTD-753-06745
...
14
Chain 20" MTD-913-05044
...
15
Oil Pump Assembly MTD-753-06387
...
16
Rear Handle Cover Assembly w/switch MTD-753-06734
...
17
Top Cover Assembly (Incl. 40) MTD-753-06456
...
18
Air Cleaner Assembly MTD-753-06457
...
19
Air Cleaner Cover Assembly MTD-753-06458
...
20
Bar Nut MTD-753-06460
...
21
Clutch Nut MTD-753-06461
...
22
Trigger Release MTD-753-06464
...
23
Throttle Trigger MTD-753-06465
...
24
Trigger Release Spring MTD-753-06466
...
25
UPPER GRIP SCREW MTD-753-06467
...
26
SCREW 8/16 x .500 MTD-753-06470
...
27
Throttle Clamp Screw MTD-753-06470
...
28
Choke Lever Assembly MTD-753-06737
...
29
Choke Rod MTD-753-06474
...
30
Rear Handle Assembly MTD-753-06738
...
31
Grip Anti-vibration Washer MTD-753-06477
...
32
Grip Anti-vibration Screw MTD-753-06478
...
33
Throttle Clamp Washer MTD-753-06479
...
34
Boot MTD-753-06739
...
35
Handle Assembly MTD-753-06483
...
36
Tension Screw & Nut Assembly MTD-753-06484
...
37
Inner Guide Plate MTD-753-06740
...
38
Guide Plate Screw MTD-753-06487
...
39
Outer Guide Plate MTD-753-06488
...
40
Screen MTD-753-06504
...
41
Oil Cap MTD-753-06505
...
42
Fuel Cap MTD-753-06741
...
43
Ground Wire MTD-753-06510
...
xx
Case (optional) MTD-753-06489
...
xx
Wrench (optional) MTD-753-06490
...
...
...
